Set Your Printing Preferences on a Windows PC

Set the Printable Area

This functionality allows you to adjust the printable area settings for
standard CD/DVD/BD 120 mm media, which sets the outer and inner
diameters to print the disc label without overlapping the disc edges.
Tip: Printable area settings created within a CD Designer label file will
override the printer and fax settings on Windows.
Access printing preferences. Refer to page 15 for instructions.
1.
2. Select the Advanced tab.
3. View or change the Printable Area preferences.
a. Select the Modify button. The Printable Area Settings window
opens.
b. Select the Unit of measurement.
i. For 1.0 mm, select the 1.0 mm radio button.
ii. For 0.1 mm, select the 0.1 mm radio button.
c. To modify only Standard Area settings, select the Standard radio
button.
i. Enter the desired Outer Diameter.
ii. Enter the desired Inner Diameter.
d. To print on a disc with a stacking ring, select the Advanced radio
button. The Hub Area settings display.
i. Enter the desired Outer Diameter for the hub.
ii. Enter the desired Inner Diameter for the hub.
e. Select OK to save the changes. The Printable Area Settings window
closes.
4. When you have made the desired choices in the Rimage Everest 400
Printing Preferences window, select Apply.
5. Select OK to close the Rimage Everest 400 Printing Preferences window.
2002552_A

Adjust the Print Alignment and Color Density

1.
2. Select the Utility tab.
3. Select the Status Monitor...
4. Select the Printer
For more information visit rimage.com/support
Access printing preferences. Refer to page 15 for instructions.
button. The Rimage Everest
400 Status Monitor window
opens with the Status tab
active.
Tip: On the Status tab, you
can view the progress of a
print job, the type of print
ribbon installed, and the
estimated number prints
remaining.
Information tab to view or
change the Print Alignment
and Color Density settings,
or view the Everest 400
Printer Status.
Tip: The Printer Information tab also displays the current firmware
version and serial number of your Everest 400 printer.
17
