2.4

AUTO UPLOAD METER REGISTRATION

Meter Registration is only required if you are using Auto Upload with a OneTouch Ultra Meter
and the Connection Cable. It is not required for OpenChoice with any meter.
To register the devices connect the OneTouch Ultra Meter and Receiver following these steps:
1. Make sure the OneTouch Ultra Meter display is off (screen is blank) before connecting the Con-
nection Cable. To turn the display off, press the M button once.
2. Using the optional Connection Cable, follow the steps below. You must do these steps in order.
a. First plug the cable into the connection port of the meter.
(The connection port is at the bottom of the meter).
b. Second connect the wide end of the cable into the Receiver. Make sure the raised Push
button on the cable is facing down.
3. After a few seconds, "PC" will appear on the OneTouch Ultra Meter screen
(shown here on the right):
4. You will see the following screen below. If you would like, you can also set your Receiver to beep
and vibrate when this screen appears (see Chapter 2, Section 2.3, "Setting Your Alerts").
5. Press the button to "accept" this new meter. The symbol
OK
above will disappear and the Receiver will return to the 3-Hour
Glucose Trend Graph. This means your registration is complete.
(Note: This process may take a few minutes to complete.)
a. Press the Push button (facing down) on the Connection Cable
to remove it.
b. It doesn't matter if you remove the cable from the meter or the SEVEN PLUS
System first.
6. Check to see that the Receiver and meter have the same time.
7. Once you have registered, all new fingerstick readings taken and uploaded from this meter will
be used to calibrate your System.
40 | SEVEN PLUS Continuous Glucose Monitoring System
M C
New Meter Screen
