UG-690
EVALUATION BOARD SOFTWARE
STARTING THE SOFTWARE
After the
EVAL-AD7405FMCZ
are correctly connected to your PC, the evaluation software can
be started.
1.
From the Start menu, select Programs > Analog Devices >
AD7405. The main window of the software then opens
(see Figure 14).
2.
If the
EVAL-AD7405FMCZ
port via the
EVAL-SDP-CH1Z
launched, a connectivity error displays (see Figure 13).
Connect the evaluation board to the USB port of the PC,
wait a few seconds, click Rescan, and follow the instructions.
and
EVAL-SDP-CH1Z
boards
is not connected to the USB
when the software is
EVAL-AD7405FMCZ User Guide
Rev. 0 | Page 12 of 20
Figure 13. Connectivity Error Alert
