EVAL-AD7405FMCZ User Guide

SAVING FILES

The software can save the current captured data for future
analysis. The software also has the ability to save or print a
screenshot of the currently displayed window.
Saving Captured Data
To save data, from the File menu, select Save Captured Data,
The Save As dialog box shown in Figure 20 opens. Save the file
to an appropriate folder location. Waveform data is saved in .csv
format and may be opened for further analysis in other software,
such as Excel and MATLAB®.
Figure 20. Dialog Box for Saving a File
Saving Screenshot
To save a screenshot, from the File menu, select Take
Screenshot. The Select the JPEG file to write dialog box in
Figure 20 opens. Save the file to an appropriate folder location.
Screenshots are saved in .jpeg format and can be viewed with
any picture viewer/editor.
Figure 21. Dialog Box for Saving a Screenshot

PRINT SCREENSHOT

To print a screenshot, from the File menu, select Print
Screenshot. The screenshot is sent to the default printer.
No dialog will appear when printing a screenshot.

OPENING FILES

Loading Captured Data
The software can load previously captured data for analysis.
From the File menu, select Load Captured Data. Only data
that was previously captured and saved can be opened. The raw
data is used to rebuild the histogram and ac spectrum analyses
upon being loaded into the evaluation platform.
When Load Captured Data is selected, the Open file dialog
box in Figure 22 opens for loading an appropriate file. The
evaluation software expects that a previously generated
waveform file is in .csv format.
Rev. 0 | Page 19 of 20
Figure 22. Dialog Box for Opening a File
UG-690
