1/3 CLIPPED WING CUB 1/3 CLIPPED WING CUB INDEX BEFORE YOU BEGIN PARTS LIST ASSEMBLY P.3-P.12 SAFETY PRECAUTIONS P.12 BEFORE YOU BEGIN Read through the manual before you begin, so you will have an overall idea of what to do.
Wing Struts PM4x20mm d4xD9mm 280mm 260mm Washer PM4x20mm Screw 174mm Main Wing Strut 184mm 3.5mm 373mm 331mm d4xD12mm Washer M4 Nylon Insert Lock Nut PM4x20mm d4xD9mm Washer M4 Nylon Insert Lock Nut d4xD12mm Washer Bottom View Stabilizer & Elevator Temporary install the main wing, adjust (Stabilizer) leveling of the stabilizer to make it as parallel to the main wing as possible.
Tail Landing Gear PA 3.5x16mm Screw PA3.5 x16mm PWA 2 . 5x12mm Screw Spring PWA2.5 x 12mm M3x3mm Set Screw 2.5mm COPPER PLATE 1.5x10x60mm 1.5mm Bottom View Main Landing Gear PM4x30mm Screw PM4x30mm d4xD9mm Washer PA 3x14mm Screw 1.5mm ALU.PLATE PA 4x25mm Screw 3x15x77mm PA4x25mm...
Page 7
Engine M6x30 SOCKET HEAD SCREW d6xD15mm Washer 7.2mm M6 Blind Nut SOCKET HEAD SCREW M6 Blind Nut M6x30 mm washer d6xD15mm Cowling Please refer to the attached sheet for usage of the transparent 3D template. First insert the grommet to the cowling then apply screw. PWA3x12mm Screw d2.5x8.5mm Silicon Grommet d2.5xD8.5mm...
Fuel Tank Install Wood 12x12x197mm (For Fuel Tank Position Fixing) Fuel Tank Fuel Tank 1500cc Bottom View Completed Elevator Pushrod PM4x40mm Screw M4 NYLON INSERT LOCK NUT M4 Nylon Insert Heavy Duty Horn Bracket Lock Nut M2 Nut Heavy Duty Clevis PM2x8mm PM4x40mm...
Page 9
Flying Wire Copper Tube 3mm Set Screw d3.6mm Collar Press down the center 1/3 portion PM 3x18mm Screw M3 NYLON INSERT LOCK NUT d5xD6.4x10mm M3x3mm Set SCREW Windows Window A Window B Completed COMPLETED Securely glue the windows to the fuselage. Servo Set 3x3mm Set Screw Linkage Connector...
Radio Equipment lnstall and arrange the servo as shown in the diagram. Battery Sponge Receiver Throttle Pushrod Plastic tube D1.2x480mm Throttle Servo d2xD3x300mm Bottom View Pilot PWA 2x12mm Screw PWA2x12mm Screw PC101110A Wind Shield PWA2.3x12mm Screw d1.5x6.5mm Silicon Grommet PWA2.3x12mm M2 NYLON INSERT LOCK NUT PM2x14mm Screw 5xD6...
Page 11
Main Wing Step 1. Insert the aluminum wing tube with the pre-drilled hole end into the right wing. Align the lines marked at the wing root and wing tube and apply the PM3x30mm machine screw through the pre-drilled hole on top of the wing. ( please confirm the PM3x30mm Screw alignment of the hole by putting a 2.5mm diameter rod through the pre-drilled wing hole before applying the screw ) The hole on the wing tube is pre-threaded, do not over...
Page 12
Wing Struts PM4x16mm Screw Washer d4x D12mm Washer d4xD12mm PM4x16mm M4 NYLON INSERT LOCK NUT M4 NYLON INSERT LOCK NUT Wing Setting Adjust the wing and fuselage configuration as shown in the diagrams. A = A ' B = B ' C = C ' P.11...
# Pre-flight adjustment must be done before flying, it is very dangerous to fly a badly pre-adjusted aircraft. # 1/3 CLIPPED WING CUB is specially designed to be powered by 80c.c.gasoline engine, using a more powerful engine does not mean better performance. In fact, over powered engine may cause severe damage and injuries.
Page 14
LINKAGE CONNECTOR HW7111050 & HW7111060 Drill 2mm hole at servo horn. Insert linkage connector into servo horn. Make sure shoulder of screw is cleared from servo horn. Add washer to reduce play if necessary. Shoulder Tighten up the round nut against the shoulder.
Page 15
Usage of the transparent 3D template This transparent 3D template is used for position guidance of the actual cutting of the pre-painted cowling. Simply cut the transparent 3D template to fit your engine and exhaust pipe, then slide onto the actual cowling and use as template to mark the openings required for final cutting.
