THE WORLD MODELS PIPER J-3 CUB 26s Instruction Manual page 8

13 Canopy
PWA2.3x8mm Screw
4
d1.5xD6.5mm
Silicon Grommet
4
d1.5xD6.5mm
Silicon Grommet
14
Cowling
PWA2.6x12mm Screw
4
d1.5xD6.5mm
Silicon Grommet
4
PWA2.6x12mm
Silicon Grommet
d1.5xD6.5mm
Fuselage
PWA2.6x12mm
Cowling
15
Servo Set
3x3mm Set Screw
1
Linkage Connector
1
M2 Nut
1
2mm Washer
2
A002SPO24781009
PWA2.3x8mm
Please refer to the attached sheet for
usage of the transparent 3D template.
First insert the grommet to
the cowling then apply screw.
Washer
2m m
Nut
M2
Please refer to the attached sheet for linkage connector installation.
d1.5xD6.5mm
Silicon Grommet
3mm
2mm
2mm
Washer
P.7
1.5mm
Throttle Servo.
