Control Throws

Rudder
Elevator
Aileron
22
C.G.
55mm
2.16in
Warning!

Important Safety Precautions

# F i r s t t i m e f l y e r s h o u l d n e v e r f l y b y h i m s e l f / h e r s e l f . A s s i s t a n c e f r o m e x p e r i e n c e d
f l y e r i s a b s o l u t e l y n e c e s s a r y.
# P r e - f l i g h t a d j u s t m e n t m u s t b e d o n e b e f o r e f l y i n g , i t i s v e r y d a n g e r o u s t o f l y a b a d l y
p r e - a d j u s t e d a i r c r a f t .
#
e n g i n e , u s i n g a m o r e p o w e r f u l e n g i n e d o e s n o t m e a n b e t t e r p e r f o r m a n c e . I n f a c t ,
o v e r p o w e r e d e n g i n e m a y c a u s e s e v e r e d a m a g e a n d i n j u r i e s .
# M a k e s u r e t h e a i r f i e l d i s s p a c i o u s , n e v e r f l y t h e p l a n e t o o c l o s e t o p e o p l e a n d n e v e r
g e t t o o c l o s e t o a r u n n i n g p r o p e l l e r.
# I f y o u f i n d w r i n k l e s o n t h e c o v e r i n g a s a r e s u l t o f w e a t h e r c h a n g e s , y o u c a n u s e h o t
i r o n t o r e m o v e t h e w r i n k l e s . P l e a s e b e g i n w i t h l o w e r t e m p e r a t u r e s e t t i n g a n d
g r a d u a l l y r a i s e t h e t e m p e r a t u r e u n t i l t h e w r i n k l e s a r e g o n e . To o h o t a n i r o n m a y
d a m a g e t h e c o v e r i n g . D o n ' t u s e h o t i r o n n e a r t h e s e a m s o r e d g e s , h o t i r o n w i l l
m e l t t h e g l u e a n d s h r i n k t h e c o v e r i n g a t t h e s a m e t i m e , c a u s i n g t h e s e a m s t o p u l l a w a y.
# C h e c k a n d r e - t i g h t e n u p a l l f a c t o r y a s s e m b l e d s c r e w s , u s e t h r e a d l o c k e r i f n e c e s s a r y.
A002SPO24781009
14mm
14mm
The ideal C.G. position is 55mm (2.16 in) behind the leading edge measured
at where the wing meets the fuselage. In order to obtain the C.G. specified,
add weight to the fuselage or move the battery position. Check the C.G. before
flying.
If you are converting this model to electric, please move the C.G. forward 10% of
current C.G. distance from leading edge to compensate for weight of fuel.
http://www.theworldmodels.com/para/instruction/instructionManuals.php
i s s p e c i a l l y d e s i g n e d t o b e p o w e r e d b y 2 C 0 . 2 5 - 0 . 3 2 o r 4 C 0 . 3 0
Adjust the control throws as shown in
the diagram. These throws are good for
general flying. You can adjust according
to your personal preference.
28mm
28mm
P.10
5mm
5mm
