Main Wing
Pre-glued
2
Aileron Servo
Screw
PB2x30mm
6
Screw
PWA2x8mm
8
1.5mm
A053PO28891307
Aileron Servo Lead
Bottom View
Ø1mm pilot holes for World Models tri-horn are pre-drilled.
Please look for pin-hole marks at under side of control surfaces.
PWA 2 x 8mm
Bottom View
P.3
TWM PL8210010
CLEVIS WRENCH
PWA2x8mm
Straper
Clevis
Fuel Tube
Ø6x5mm
1mm
Pushrod Ø1.8x120mm
Fuel Tube
6x5mm
Ø
PB2x30mm
Tri-Horn
M3x22mm
