16
Elevator Pushrod
PB2x16mm Screw
6
Tri-horn
M3x22mm
Clevis
Fuel Tube
Ø6x5mm
Servo Set
17
3x3mm Set Screw
Linkage Connector
M2 Nut
2mm Washer
18
Servo Tray
Servo Tray
3x152x218mm
A053PO28891307
PB2x16mm
1
Throttle Pushwire
1
1
2
Please refer to the attached sheet for linkage connector installation.
Plywood
Ø1mm pilot holes for The World Models tri-horn are pre-drilled.
Please look for pin-hole marks at under side of control surfaces.
2mm
Washer
2mm
2mm
2mm
Washer
M2 Nut
P.9
Pushrod
Ø1.8x995mm
TWM PL8210010
CLEVIS WRENCH
3mm
Throttle Servo
