Main Wing
M3x15mm Socket Head Screw
12
d3xD7mm Washer
8
M3 Nylon Insert Lock Nut
4
Bottom View
4
Fuel Tank
1
Double-sided Tape 40x100mm
A053PO28891307
M3x15mm
Main Wing Strut
M3 Nylon Insert Lock Nut
Cable Tie (For Fuel Tank)
1.5x5x400mm
2
202mm
(7.95in.)
69mm
(2.72in.)
d3xD7mm
Washer
3mm
Cable Tie
(For Fuel Tank)
1.5x5x400mm
UP
P.4
193mm
(7.59in.)
380mm
369mm
(14.96in.)
(14.52in.)
M3x15mm
d3xD7mm Washer
Double-sided Tape 40x100mm
3
Completed
