TuffStuff SP-404 Assembly Instructions Manual page 7

28
42
27
FIG. 17 Route the Cable (#42)
Upright (#27), as shown above.
42
FIG. 19 Route the Cable (#42)
Labeled F) and attach the pulley to the
using one Hex Head Cap Screw 3/8-16 X 2 1/2 (#21), two Flat Wash-
ers SAE 3/8" (#15), and one Nylon Insert Jam Lock Nut 3/8-16 (#19).
SP-404 Lat/Mid-Row
through the openings of the
28
F
over a Nylon Pulley 4 1/2 Rd. (#13-
Top Pulley Assembly (#28)
42
Front FIG. 18 Attach two Nylon Pulleys 4 1/2 Rd. (#13-Labeled C, E) to
the Front Upright
them into place using two Hex Head Cap Screws 3/8-16 X 2 1/2
(#21), four Flat Washers SAE 3/8" (#15), and two Nylon Insert Jam
Lock Nuts 3/8-16 (#19). Next, insert the
Pulley 4 1/2" Rd. (#13-Labeled D) to the
bracket and secure the pulley into place using one Hex Head Cap
Screw 3/8-16 X 2 (#22), two Flat Washers SAE 3/8" (#15), and one
Nylon Insert Jam Lock Nut 3/8-16 (#19). Be sure the cable is routed
properly into the groove of the Nylon Pulleys.
FIG. 20 Next, route the
Plastic Shroud Lid (#8) and the
Owner's Manual: Assembly Instructions
28
E
C
D
27
(#27), in the position as shown above, and secure
Cable (#42)
8
4
42
Cable (#42) down through the holes of the
Top Guide Rod Retainer
29
and a Nylon
Press Bar (#29) pulley
(#4).
6
