TUFFSTUFF FITNESS INTERNATIONAL
OWNER'S MANUAL
OWNER'S MANUAL
Maintenance & Assembly Instructions
IMPORTANT: KEEP THIS MANUAL FOR FUTURE REFERENCE
*Shown with AXT-225 Deluxe Home Gym
(Sold separately)
Leg Press Option for XT Gym
SXT-LP
Series
SXT-LP_Rev1
Revision Date 2-14-2018

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SXT-LP and is the answer not in the manual?

Questions and answers

Related Manuals for TuffStuff SXT-LP

Summary of Contents for TuffStuff SXT-LP

  • Page 1 TUFFSTUFF FITNESS INTERNATIONAL OWNER’S MANUAL OWNER’S MANUAL Maintenance & Assembly Instructions IMPORTANT: KEEP THIS MANUAL FOR FUTURE REFERENCE *Shown with AXT-225 Deluxe Home Gym SXT-LP (Sold separately) Leg Press Option for XT Gym Series SXT-LP_Rev1 Revision Date 2-14-2018...

  • Page 2: Table Of Contents

    CABLE INSPECTION ..................Page 13 STEP 1 SXT-LP+AXT-225 ................Page 14 STEP 1 SXT-LP+SXT-550 ................Page 15 STEP 2-5 .......................Page 16-19 STEP 6 SXT-LP+AXT-225 CABLE ROUTING ........Page 20-21 STEP 6 SXT-LP+SXT-550 CABLE ROUTING ........Page 22-23 STEP 7-9 .......................Page 24-26 PARTS LIST ......................Page 27 PRE ASSEMBLED COMPONENTS ............Page 28-29...

  • Page 3: Overhead Specifications

    OVERHEAD SPECIFICATIONS SXT-LP+AXT-225 L 75” X W 76” X H 84” PRODUCT WEIGHT 196 lbs. MAX-LOAD WEIGHT LIMIT - 200 lbs. SXT-LP+SXT-550 L 84” X W 74” X H 84” PRODUCT WEIGHT 196 lbs. MAX-LOAD WEIGHT LIMIT - 200 lbs.

  • Page 4: Danger, Warning, & Caution Labels Information

    Carefully read ALL Danger, Warning & Caution labels posted on the machine www.tuff stuffi tness.com Leg Press Option for XT Gym Series...
  • Page 5 Carefully read ALL Danger, Warning & Caution labels posted on the machine Leg Press Option for XT Gym Series www.tuff stuffi tness.com...
  • Page 6 Carefully read ALL Danger, Warning & Caution labels posted on the machine www.tuff stuffi tness.com Leg Press Option for XT Gym Series...
  • Page 7 Carefully read ALL Danger, Warning & Caution labels posted on the machine Leg Press Option for XT Gym Series www.tuff stuffi tness.com...
  • Page 8 Carefully read ALL Danger, Warning & Caution labels posted on the machine www.tuff stuffi tness.com Leg Press Option for XT Gym Series...
  • Page 9 TuffStuff authorized dealer or TuffStuff customer service personnel. Immediately report any piece of equipment that is not functioning properly. DO NOT ATTEMPT to use or fix any piece of equipment yourself. Contact TuffStuff immediately. ASTM F1749-96 TUFFSTUFF FITNESS INTERNATIONAL, CHINO, CA 91710...

  • Page 10: Important Safety Instructions

    If you have not participated in a regular exercise program, smoke or have signs of high blood pressure, you must obtain a medical exam or consult with your personal physician before performing any SXT-LP exercises illustrated in this manual. SERIOUS INJURY OR DEATH CAN OCCUR...

  • Page 11: Registration, Service & Assembly

    Registration, Service & Assembly Thank you for purchasing the SXT-LP Leg Press Option for XT Gym Series. This machine is part of the Tuff Stuff line of quality strength training equipment. To maximize your use of the equipment, please study the Owner’s Manual thoroughly.

  • Page 12: Inspection/Maintenance

    Inspection/Maintenance Perform regular maintenance (see Inspection Label). Pay special attention to areas most susceptible to wear and tear, including but not limited to cables, pulleys and rubber grip. TFI recommends you maintain a service contract with a TFI Authorized Dealer or a Professional Service Company approved by TFI.

  • Page 13: Cable Inspection

    Cable Inspection WARNING: THE FOLLOWING CONDITIONS MAY INDICATE A WORN CABLE. REPLACE IMMEDIATELY. “NECKING”, STRETCHED CABLE COVERING A CRACK IN THE CABLE COVER A TEAR IN THE CABLE COVER A BREAK ON THE CABLE CABLE END SLIPPING OUT IMPORTANT NOTE: DAMAGED OR WORN CABLE (AS SHOWN ABOVE) MAY DAMAGE THE PULLEY(S).

  • Page 14: Step 1 Sxt-Lp+Axt-225

    Step 1 SXT-LP+AXT-225 NOTE: 1. It is strongly recommended that two people participate in the assembly of this unit. 2. Some parts not shown for clarity. Step 1 Assembly List 3. If AXT-225 unit was previously assembled, it may be...

  • Page 15: Step 1 Sxt-Lp+Sxt-550

    Step 1 SXT-LP+SXT-550 NOTE: Step 1 Assembly List 1. It is strongly recommended that two people Item # Description Qty. participate in the assembly of this unit. CROSS BRACE FLAT WASHER SAE Z/P 1/2” HEX HEAD CAP SCREW GR-5 Z/P 1/2-13 X 3 1/4...

  • Page 16: Step 2

    Step 2 Step 2 Assembly List Item # Description Qty. CROSS BRACE MAIN FRAME FLAT WASHER SAE Z/P 3/8” HEX HEAD CAP SCREW GR-5 Z/P 3/8-16 X 1 SPLIT LOCK WASHER Z/P 3/8” NOTE Wire string will be used to guide the cable on step 6.
  • Page 17 Step 3 Step 3 Assembly List Item # Description Qty. CARRIAGE LINEAR SHAFT Note: 1. Slide linear shaft into carriage. Rear View Loosely Tighten Loosely Tighten Loosely tighten all hardware in this step. Leg Press Option for XT Gym Series www.tuff stuffi tness.com...
  • Page 18 Step 4 Step 3 Assembly List Item # Description Qty. CARRIAGE LINEAR SHAFT HEX HEAD CAP SCREW GR-5 Z/P 3/8-16 X 1 1/4 SPLIT LOCK WASHER Z/P 3/8” FLAT WASHER Z/P 3/8 ID X 1 1/2 OD X 3/16 NOTE: 1.
  • Page 19 Step 5 Step 5 Assembly List Item # Description Qty. LINEAR SHAFT HOUSING HEX HEAD CAP SCREW GR-5 Z/P 3/8-16 X 1 1/4 HEX HEAD CAP SCREW GR-5 Z/P 3/8-16 X 4 3/4 NYLON INSERT THIN PATTERN LOCK NUT Z/P 3/8-16 SPLIT LOCK WASHER Z/P 3/8”...

  • Page 20: Step 6 Sxt-Lp+Axt-225 Cable Routing

    Step 6 SXT-LP+AXT-225 Cable Routing USE EXISTING HARDWARE USE EXISTING HARDWARE www.tuff stuffi tness.com Leg Press Option for XT Gym Series...
  • Page 21 NYLON INSERT LOCK NUT Z/P 5/16-18 Note: 1. Skip to next step if you will be installing the SXT-LP on a SXT-550 unit. 2. Some parts not shown for clarity. 3. Assemble the pulleys shown below at the same time you route the cable.

  • Page 22: Step 6 Sxt-Lp+Sxt-550 Cable Routing

    Step 6 SXT-LP+SXT-550 Cable Routing USE EXISTING HARDWARE www.tuff stuffi tness.com Leg Press Option for XT Gym Series...
  • Page 23 Step 6 Assembly List Item # Description Qty. LEG PRESS CABLE (SXT-LP+SXT-550) BUTTON HEAD SOCKET CAP SCREW GR-8 Z/P 3/8-16 X 1 3/4 BUTTON HEAD SOCKET CAP SCREW GR-8 Z/P 3/8-16 X 4 1/2 FLAT WASHER SAE Z/P 3/8” NYLON INSERT THIN PATTERN LOCK NUT Z/P 3/8-16...

  • Page 24: Step 7

    Step 7 Step Assembly List Item # Description Qty. FOOT PLATE FLAT HEAD SOCKET CAP SCREW Z/P 3/8-16 X 2 3/4 FLAT WASHER SAE Z/P 3/8” NYLON INSERT THIN PATTERN LOCK NUT Z/P 3/8-16 RUBBER FOOT PLATE COVER www.tuff stuffi tness.com Leg Press Option for XT Gym Series...
  • Page 25 Step 8 Step Assembly List Item # Description Qty. HANDLES BUTTON HEAD SOCKET CAP SCREW GR-8 Z/P 3/8-16 X 3 FLAT WASHER SAE Z/P 3/8” NYLON INSERT THIN PATTERN LOCK NUT Z/P 3/8-16 FLAT WASHER Z/P 3/8 ID X 1 1/2 OD X 3/16 Leg Press Option for XT Gym Series www.tuff stuffi tness.com...
  • Page 26 Step 9 Step Assembly List Item # Description Qty. BACK PAD SEAT PAD BUTTON HEAD SOCKET CAP SCREW GR-8 Z/P 3/8-16 X 1 1/4 BUTTON HEAD SOCKET CAP SCREW GR-8 Z/P 3/8-16 X 3 FLAT WASHER SAE Z/P 3/8” Note: After completing this step adjust the cable by loosening the fi...

  • Page 27: Parts List

    Parts List SXT-LP_REV1 COLOR CHART GRAY= SUB-ASSEMBLY PARTS SXT-LP BLACK= HARDWARE Parts List Description Description Item No. Rev. Part No. Qty. Item No. Rev. Part No. Qty. ADJUSTABLE TUBE UP7767 NYLON INSERT THIN PATTERN LOCK NUT Z/P 3/8 16 BNH2026...

  • Page 28: Pre Assembled Components

    Pre Assembled Components *10 UP7775X1 55 64 *7 UP7773X1 *11 UP8423X1 www.tuff stuffi tness.com Leg Press Option for XT Gym Series...
  • Page 29 Pre Assembled Components Leg Press Option for XT Gym Series www.tuff stuffi tness.com...

  • Page 30: Rail Wheel Replacement Steps

    Rail Wheel Replacement Step 1 DISCONNECT CABLE HERE AND SET ASIDE. Step 2 NOTE: 1. HAVE ONE PERSON HOLD THE LINEAR SHAFTS WHILE YOU REMOVE THE LINEAR SHAFT HOUSING AND THEN SLIDE THE CARRIAGE OUT. www.tuff stuffi tness.com Leg Press Option for XT Gym Series...
  • Page 31 Rail Wheel Replacement Step 3 Step 4 INSTALLATION IS THE REVERSE OF REMOVAL. (DO NOT INSTALL THE SEAT PAD UNTIL COMPLETING RAIL WHEEL ADJUSTMENT ON NEXT PAGE) Leg Press Option for XT Gym Series www.tuff stuffi tness.com...

  • Page 32: Rail Wheel Adjustment

    Rail Wheel Adjustment Step 1 www.tuff stuffi tness.com Leg Press Option for XT Gym Series...
  • Page 33 Rail Wheel Adjustment Step 2 Leg Press Option for XT Gym Series www.tuff stuffi tness.com...

  • Page 34: Basic Exercise Guide

    Basic Exercise Guide Use this equipment only for the exercises as shown. Know your limitations. If you are new to weight training, always start with lighter weight, learn how to perform the exercise correctly and train at a controlled rate of speed. Warm up properly with stretchings, calisthenics or cardiovascular exercises.

  • Page 35: Notes

    Notes Leg Press Option for XT Gym Series www.tuff stuffi tness.com...

  • Page 36: Warranty

    No modification of this warranty or waiver of its terms shall be binding on either party unless approved in writing by an authorized representative of the party. Contact TuffStuff Fitness International, Inc. at 13971 Norton Avenue, Chino, CA 91710, before returning any defective equipment.
