A S S E M B L Y I N S T R U C T I O N S
TABLE OF CONTENTS:
Pg. 1
Pg. 1
Assembly
Pg. 2 - Pg. 9
Pg. 8
Cable Mapping Diagram
Fold-out Pg. 10
Exploded View Diagram
Fold-out Pg. 11
Pg. 12
Back Page
SP-415
Inner/Outer Thigh
© 2003 TuffStuff Fitness Equipment, Inc.
A m e r i c a ' s P r e m i e r E x e r c i s e E q u i p m e n t
58"
L 55 3/4" W 58" H 54 3/4"
Revision Date 06-03-02
55 3/4"
SP-415 Rev0
