COLOR CHART
GRAY= SUB-ASSEMBLY PARTS
BLACK= HARDWARE
Item No.
Description
1
WEIGHT STACK FRAME 60" LONG LAT
2
WEIGHT SHROUD 60" LONG
3
GUIDE ROD 3/4 X 59-5/8
4
GUIDE ROD RETAINER
5
10 LB CAST WEIGHT PLATE GREY
6
10 LB TOP PLATE W/ADJ. SLTR BAR 19 WTS
7
PLASTIC SHROUD GAP COVER
8
PLASTIC SHROUD LID 5/8 X 14 1/8 X 10 (SP-404)
9
PLASTIC SHROUD EDGE PROTECTOR 1/8 X 26 3/4
10
EDGE PROTECTOR GRAY 60" LONG
11
URETHANE BUMPER 1 3/4
12
RUBBER DONUT 3/4 X 2 1/2
13
NYLON PULLEY 4 1/2 RD. WHITE
14
U-STYLE TAPPED HOLE NUT 1/4-20
15
FLAT WASHER SAE B/O 3/8"
16
FLAT WASHER SAE B/O #12 (1/4")
17
HEX HEAD CAP SCREW GR-5 B/O 1/4-20 X 3/4
18
NYLON INSERT LOCK NUT B/O 1/2-13
19
NYLON INSERT JAM LOCK NUT B/O 3/8-16
20
HEX HEAD CAP SCREW GR-5 B/O 1/2-13 X 3-1/2
21
HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 2-1/2
22
HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 2
23
FLAT HEAD SOCKET CAP SCREW B/O 3/8-16 X 3
24
RUBBER GROMMET 3/4" ID (2867-012)
25
FLAT WASHER SAE B/O 1/2"
26
BASE FRAME
27
FRONT UPRIGHT
28
TOP PULLEY ASSEMBLY
29
PRESS BAR
30
SEAT FRAME
31
ADJUSTABLE SEAT PAD TUBE
32
ADJUSTABLE CHEST PAD TUBE
33
ADJUSTABLE FOOT ROLL TUBE
34
HANDLE
35
FOOT ROLL TUBE
36
LAT BAR HOLDER
37
PIVOT AXLE
38
SEAT PAD
39
CHEST PAD
40
WEAR COVER (OPTIONAL)
41
FOOT ROLL 1 X 5 1/2 X 7 1/4
42
LAT/MID-ROW CABLE
43
LAT BAR 48"
44
RUBBER GRIP 1 X 6 1/4
45
RUBBER BUMPER 3/8 X 2 1/2
46
BRONZE BUSHING 1 X 1 1/4 X 3/4 X 1 1/2 X 1/8
47
RUBBER GRIP 1 ID X .125 X 15
48
ALUMINUM CAP 1" RD. (CAP-100)
49
SOCKET SET SCREW ALLOY 10-32 X 1/8
50
PUSH PULL PIN 1/2 X 3 1/2 REGULAR
51
BALL BEARING #W 516
52
STEEL BUMPER WASHER Z/P 3/8"
13
SP-404 Lat/Mid-Row
Parts List
Part No.
Qty
Item No.
UP0950
1
53
TURN/PULL PIN W/KNOB AND LOCK
UP0776
2
54
FLAT PHILLIPS MACHINE SCREW 8-32 X 1/4
UP0777
2
55
CHROME WASHER 3/8 X 11/2
UP0842
1
56
CHROME WASHER 5/8 X 5/32 X 1 1/2
BNH0904
19
57
METAL HINGE
BNH1100
1
58
PLASTIC INSERT CAP 2 X 3
BNH1083
1
59
PLASTIC INSERT CAP 2" SQ.
BNH1181
1
60
PLASTIC END CAP 2 X 3 (SIMPLEX LINE)
BNH1179
2
61
PVC 1 X 7 1/4
BNH1176
2
62
PLASTIC INSERT CAP "A" 1 RD.
BNH0229
3
63
PLASTIC INSERT CAP "B" 1 RD.
BNH0068
2
64
BUTTON HEAD SOCKET CAP SCREW B/O 3/8-16 X 1
BNH0556
6
65
HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 1 1/4
BNH0708
8
66
HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 1-1/2
BNH0239
35
67
HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 2 3/4
BNH0877
8
68
HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 4 1/4
BNH0890
8
69
HEX HEAD CAP SCREW GR-5 B/O 1/2-13 X 1
BNH0212
4
70
NYLON INSERT LOCK NUT B/O 3/8-16
BNH0365
7
71
SPLIT LOCK WASHER B/O 1/2"
BNH0263
4
72
SPLIT LOCK WASHER B/O 3/8"
BNH0276
5
73
RETAINING SNAP RING EXT. PLAIN .925 X 1 X .042
BNH0279
1
74
FINISHED HEX JAM NUT Z/P 5/8-18
BNH0787
2
75
ROD END BALL JOINT F-10S FK 5/8-18 X 3/4
BNH0401
2
76
HEX HEAD CAP SCREW GR-8 Z/Y 5/8-18 X 1
BNH0238
12
77
SPLIT LOCK WASHER B/O 5/8"
UP0934
1
78
SPLIT LOCK WASHER Z/P 1/2"
UP0935
1
79
CABLE HEX TAP BOLT Z/P 1/2-13 X 3
UP0936
1
80
FINISHED HEX NUT B/O 1/2-13
UP0937
1
81
CLEVIS BRACKET 3/16"
UP0938
1
82
NYLON BALL 1 3/4 X 1/4
UP0939
1
83
SHOULDER BOLT ALLOY 3/8 X 3/4
UP0940
1
84
NYLON INSERT LOCK NUT B/O 5/16-18
UP0941
1
85
SNAP LINK Z/P 8MM X 80MM
UP0942
2
86
COIL CHAIN Z/P 3/16"
UP0943
1
87
PLASTIC SHROUD GAP COVER CONNECTOR
UP0327
1
88
HEX KEY 7/32"
UP0944
1
89
HEX KEY 3/16"
UP0945
1
90
SELECTOR PIN W/COIL DOUBLE LOCK
UP0946
1
91
DECAL-WEIGHT NUMBERS 20-200 LBS (19 PC SET)
UP0947
1
92
HEX KEY 3/32"
UP0350
2
93
U-STYLE TAPPED HOLE NUT 3/8-16
UP0948
1
94
DECAL-SIMPLEX II (1 7/8 X 5 3/16)
BNH0295
1
95
DECAL-TUFFSTUFF (2 3/4 X 19 1/16)
BNH0296
4
96
DECAL-EXERCISE SP-404 LAT/ROW 4 1/2 X 19 1/4
BNH0511
1
97
DECAL-LARGE TUFFSTUFF LOGO DIAMOND SHAPE
BNH0527
4
98
DECAL-ADJUST CABLE HERE
BNH1072
2
99
DECAL-FOR BEST PERFORMANCE 1-1/4 X 1-1/2
BNH0537
2
100
DECAL-DANGER TIGHTEN THIS RET..., 3/4 X 1-1/2
BNH0473
4
101
DECAL-CAUTION 1 3/4 X 5-1/2 HORIZONTAL
BNH0520
2
102
DECAL-WARNING KEEP HANDS AND FINGERS...
BNH0628
2
103
DECAL-CAUTION LAT BAR HOLDER 5 X 1
BNH0498
1
104
SUPER LUBE TEFLON LUBRICANT 82340
Description
SP-404 Lat/Mid-Row
Part No.
Qty
BNH0989
1
BNH0408
1
BNH1015
2
BNH1172
2
BNH0046
2
BNH0052
2
BNH0012
2
BNH0606
3
BNH1023
2
BNH0812
2
BNH0813
2
BNH0115
2
BNH0273
6
BNH0303
3
BNH0278
1
BNH0317
6
BNH0259
4
BNH0214
6
BNH0653
4
BNH0658
2
BNH0419
2
BNH0883
2
BNH1180
2
BNH0107
2
BNH0654
4
BNH0572
1
BNH1047
1
BNH0201
1
BNH0076
1
BNH0047
1
BNH0718
1
BNH0215
1
BNH0065
2
BNH0017
1
BNH1183
2
BNH0575
2
BNH0371
1
UP0466
1
BNH1202
1
BNH0372
1
BNH1211
2
BNH1199
1
BNH1200
1
BNH1189
1
BNH0360
1
BNH0789
1
BNH0143
1
BNH0142
2
BNH0126
1
BNH0620
1
BNH0140
1
BNH0704
2
