90
6
FIG. 9
Locate the
Selector Pin w/Coil (#90)
over the
Selector Bar (#6)
as shown above.
28
FIG. 11
Attach the
Top Pulley Assembly (#28)
right (#27)
using four Hex Head Cap Screws 1/2-13 X 1 (#69), four
Split Lock Washers B/O 1/2" (#71), and four Flat Washers SAE
1/2" (#25).
SP-404 Lat/Mid-Row
6
90
and slide the ring
27
to the
Front Up-
Owner's Manual: Assembly Instructions
26
FIG. 10
Attach the
Seat Frame (#30)
using two Hex Head Cap Screws 3/8-16 X 4 1/4 (#68), four Flat
Washers SAE 3/8" (#15), and two Nylon Insert Lock Nuts 3/8-16
(#70). Next, attach the
Seat Frame (#30)
using two Hex Head Cap Screws 3/8-16 X 4 1/4 (#68), four Flat
Washers SAE 3/8" (#15), and two Nylon Insert Lock Nuts 3/8-16
(#70).
34
Caution: It is strongly recommended to use another
FIG. 12
person in assisting with this assembly.
Using a rubber mallet, insert the
of the
Press Bar (#29)
and the
comes flush with both sides of the
27
30
to the
Front Upright (#27)
to the
Base Frame (#26)
37
28
29
34
Pivot Axle (#37)
through the receptacles
Top Pulley Assembly (#28)
Press Bar
(#29).
until it be-
4
