TuffStuff SP-404 Assembly Instructions Manual page 9

33
FIG. 29 Insert the Foot Roll Tube (#35)
Adjustable Foot Roll Tube (#33), as shown above.
31
FIG. 31 Affix the Seat Pad (#38)
(#31) using four Hex Head Cap Screws 3/8-16 X 1 1/4 (#65), and four
Flat Washers SAE 3/8" (#15).
SP-404 Lat/Mid-Row
30
35
into the receptacle of the
38
to the Adjustable Seat Pad Tube
Owner's Manual: Assembly Instructions
FIG. 30 Attach two Foam Rolls 1 X 5 1/2 X 7 1/4 (#41)
Roll Tube (#35) and secure them into place using two Hex Head Cap
Screws 3/8-16 X 1 1/2 (#66).
57
FIG. 32 Attach the two Metal Hinges (#57) to the axle of the
able Chest Pad Tube (#32). Be sure to position the Metal Hinges (#57)
as shown above.
41
41
to the
32
57
Foot
Adjust-
