Elevator Pushrod - THE WORLD MODELS 1/4 Clipped Wing Cub Instruction Manual

Elevator Pushrod

16
PB2x16mm Screw
6
PB2x16mm
Tri-horn
M3x22mm
Clevis
Fuel Tube
Ø6x5mm
Servo Set
17
3x3mm Set Screw
1
Linkage Connector
1
M2 Nut
1
2mm Washer
2
18 Servo Tray
Servo Tray
Plywood
3x152x218mm
A057PO29971404
Ø1mm pilot holes for The World Models tri-horn are pre-drilled.
Please look for pin-hole marks at under side of control surfaces.
Throttle Pushwire
2mm
Washer
2mm
2mm
2mm
Washer
M2 Nut
Please refer to the attached sheet for linkage connector installation.
P.9
Pushrod
Ø1.8x995mm
TWM PL8210010
CLEVIS WRENCH
3mm
Throttle Servo
