1
Main Wing
Pre-glued
2
Aileron Servo
Screw
PB2x30mm
6
Screw
PWA2x8mm
8
A057PO29971404
Aileron Servo Lead
Bottom View
Ø1mm pilot holes for World Models tri-horn are pre-drilled.
Please look for pin-hole marks at under side of control surfaces.
PWA 2 x 8mm
1mm
1mm
Bottom View
P.3
TWM PL8210010
CLEVIS WRENCH
PWA2x8mm
Fuel Tube
Straper
Ø
6x5mm
PB2x30mm
Clevis
Fuel Tube
Ø
6x5mm
Tri horn
-
Pushrod
M3x22mm
Ø
1.8x120mm
