19
CONTROL COMMAND
Remote control (CI-V) information (Continued)
• Codes for CW message contents
Command : 17 Up to 30 characters
To send CW messages, use the following character
codes.
Character ASCII code
0–9 30–39
A–Z 41–5A
a–z 61–7A
/ 2F
? 3F
. 2E
− 2D
, 2C
: 3A
L"FF" stops sending CW messages.
L "^" is used to transmit a string of characters with no
inter-character space.
• RIT frequency settings
Command : 21 00
X X X
• Repeater tone/tone squelch frequency settings
Command : 1B 00, 1B 01
q*
0 0 X
*Not necessary when setting a frequency.
• UTC Offset setting
Command : 1A 05 0096
X X X X XX
Character ASCII code
' 27
( 28
) 29
= 3D
+ 2B
" 22
@ 40
Space 20
X X X
00: + (plus)
01: – (minus)
w e
X X X
Shift direction
00: + (plus)
01: − (minus)
Offset time
0000−1400
• Selected or unselected VFO frequency settings
Command: 25
X X X X X X X X X X 0 0
Operating frequency data
00: Selected VFO
01: Unselected VFO
• Selected or unselected VFO's operating mode
and filter settings
Command: 26
Both data and filter settings can be skipped. In that
case, "DATA OFF" and the default filter setting of the
operating mode are automatically selected.
00: Selected VFO
01: Unselected VFO
X X
q Operating mode
00: LSB 05: FM
01: USB 07: CW-R
02: AM 08: RTTY-R
03: CW
04: RTTY
19-11
w Data mode setting
X X X X X X
e Filter setting
q Operating mode setting
w Data mode setting
00: Data mode OFF
01: Data mode ON
e Filter
setting
01: FIL1
02: FIL2
03: FIL3
