For Windows Nt; For Windows 2000; For Mac Osx 10.4 - NetComm NB6PLUS4WN User Manual

For Windows NT

1. Click Start, point to Settings, and then click Control Panel.
2. Double-click the Network icon.
3. The Network window appears. On the Protocols tab, check out the list of installed network components.
Option 1: If there is no TCP/IP Protocol, click Add.
Option 2: If you have TCP/IP Protocol installed, skip to Step 7.
4. Highlight TCP/IP Protocol and click OK.
5. Insert the Windows NT CD into your CD-ROM drive and type the location of the CD. Then click Continue.
6. When returning to the Network window. Open the Protocols tab, then select TCP/IP Protocol and
click Properties.
7. Enable Obtain an IP address from a DHCP server and click OK.
8. When prompted with the message below, click Yes to continue.
9. When returning to Network window, click Close.
10. When prompted with Network Settings Change dialog box, click Yes to restart your computer.

For Windows 2000

1. From the Start menu, point to Settings and then click Network and Dial-up Connections.
2. Right-click the Local Area Connection icon and then click Properties.
3. On the General tab, check out the list of installed network components.
Option 1: If there is no TCP/IP Protocol, click Install.
Option 2: If you have TCP/IP Protocol, skip to Step 6.
4. Highlight Protocol and then click Add.
5. Click Internet Protocol (TCP/IP) and then click OK.
6. When returning to the Local Area Connection Properties window, highlight Internet Protocol (TCP/IP) and
then click Properties.
7. Under the General tab, enable Obtain an IP address automatically. Then click OK.
mac OSX 10.4
1. Click the Apple icon and choose on "System Preferences".
2. Click on "Network" icon.
3. Set "Location" to "Automatic and "Show" to "Built In Ethernet".
4. Click on "TCP/IP" tab.
5. In the "Configure" option, choose "Use DHCP with automatic address".
6. Click on "Apply Now".
YML854 Rev1
