- Page 1 Quality of Service Setup Guide (NB6Plus4Wn)
- Page 2 The following Quality of Service (QoS) settings offer a basic setup example, setting up 3 devices connecting to an NB6Plus4Wn router, one with the highest priority QoS priority data traffic, one with medium priority QoS priority data traffic and the other with the lowest priority QoS priority data traffic flow. All other data packet traffic through the router assumes a default best effort setting.
- Page 3 QoS Setup Part 1: Reserving an IP address It is necessary to reserve an IP address for a device that is connecting to the NB6Plus4Wn router so that the QoS settings can manage each device and set data packet traffic priority by MAC and IP address.
- Page 4 5. Enter the MAC address of the computer/device you are connecting to the router. The MAC address is a 12 character set of numbers and letters (A-F), with every 2 characters separated by a colon. 6. Enter the IP address of the computer/device. This is the local address in the range of 192.168.1.x where x = 2 to 254.
- Page 5 8. Complete steps 4 through 7 for each device connected to the NB6 series router. Each entry will be listed in the Static IP Lease List as shown below.
- Page 6 Quality of Service (QoS) Setup: Part 2 QoS Configuration Settings 9. Select Advanced > Quality of Service Select “Enabled” checkbox. Select the Default Differentiated Service Code Point (DSCP) as BE (0x00) (Best Effort). 12. Press the Apply button.
- Page 7 High Priority QoS Queue Configuration Select Advanced > Quality of Service > Queue Configuration. Press the Add button. Set the Queue Status to Enabled. Set the Egress Interface as pppoa_0_100_1 if you are in New Zealand or pppoe_8_35_1 if you are in Australia.
- Page 8 Medium Priority QoS Queue Configuration Select Advanced > Quality of Service > Queue Configuration. Press the Add button. Set the Queue Status to Enabled. Set the Egress Interface as pppoa_0_100_1 if you are in New Zealand or pppoe_8_35_1 if you are in Australia.
- Page 9 Low Priority QoS Queue Configuration Select Advanced > Quality of Service > Queue Configuration. Press the Add button. Set the Queue Status to Enabled. Set the Egress Interface as pppoa_0_100_1 if you are in New Zealand or pppoe_8_35_1 if you are in Australia.
- Page 10 You should now have three fields in the Queue Configuration table under Advanced > Quality of Service > Queue Configuration similar to the screenshot below.
- Page 11 High Priority QoS Classification Select Advanced > Quality of Service > Traffic Classification. Press the Add button. Enter a Rule Name reflecting the High Priority QoS rule; eg. VoIP_ATA_High_Priority.
- Page 12 Leave the Rule Order as Last, set the Queue Status to Enable, set Classified Packets as IP Layer. Set the Ingress Interfaces according to how the device connects to the router. In the example above Ethernet and Wireless are selected. Enter the Source MAC Address of the device, the unique 12 character signature with every 2 characters separated by a colon(:), that you previously entered to reserve the device's IP address.
- Page 13 Medium Priority QoS Classification Select Advanced > Quality of Service > Traffic Classification. Press the Add button. Enter a Rule Name reflecting the High Priority QoS rule; eg. Games_Console_High_Priority.
- Page 14 Leave the Rule Order as Last, set the Queue Status to Enable, set Classified Packets as IP Layer. Set the Ingress Interfaces according to how the device connects to the router. In the example above Ethernet and Wireless are selected. Enter the Source MAC Address of the device, the unique 12 character signature with every 2 characters separated by a colon(:), that you previously entered to reserve the device's IP address.
- Page 15 Low Priority QoS Classification Select Advanced > Quality of Service > Traffic Classification. Press the Add button. Enter a Rule Name reflecting the High Priority QoS rule; eg. Laptop_Low_Priority.
- Page 16 Leave the Rule Order as Last, set the Queue Status to Enable, set Classified Packets as IP Layer. Set the Ingress Interfaces according to how the device connects to the router. In the example above Ethernet and Wireless are selected. Enter the Source MAC Address of the device, the unique 12 character signature with every 2 characters separated by a colon(:), that you previously entered to reserve the device's IP address.
- Page 17 71. You are now three QoS queue classification entries on the router at Advanced > Quality of Service > Traffic Classification similar to the screenshot below. Select the Restarting Router option at the bottom left of the screen or select Management > Reset Router and press the reboot button to reboot the router and complete the QoS setup.
