NetComm NB6PLUS4WN User Manual page 80

Remove Static Route
If you don't want the static route that you created, please click the icon in the Delete column from
the table.
A dialog window will appear to confirm your action. Click OK to remove the static route, or click
Cancel to keep the setting.
Example – Static Route
Here provides you an example of Static Route.
192.196.1.x
Router B
For the LAN shown above, if the PC in the subnet of 192.168.1.x wants to access the PC in the
subnet of 192.168.10.x, we can set a static route in the ADSL router, in which the destination is the
PC in the subnet 192.168.10.x and the gateway is router B. The setting would be as follows:
Destination: 192.168.10.0
Netmask: 255.255.255.0 (Standard Class C)
Gateway: 192.168.1.254 (Router B)
NB6, NB6W, NB6Plus4, NB6Plus4W, NB6Plus4Wn User Guide
80
192.196.1.1
192.168.1.254
192.168.10.1
10.1.1.1
ADSL Router
192.168.10.x
Internet
YML854Rev1
www.netcomm.com.au
