B U ILT-IN INSTALLAT ION INST R U CT IONS
ANTI-TIP BRACKET INSTALLAT ION
WARNING
Make sure that there are no electrical wires
or plumbing in the area which the screws
could penetrate.
ANTI-TIP HAR D WAR E IN CLUD E D
2 Anti-Tip Brackets
12 #12 x 64 mm PH Pan HD Zinc Screws
4 10 mm–16 x 95 mm Wedge Anchors
12 #12 Flat Washers
4 #8–18 x 32 mm PH Truss HD Screws
4 Nylon Zip-It Wall Anchors
IN STAL L C ON CRE T E WE D G E AN C HO RS
1) Drill a 10 mm diameter hole any depth
exceeding the minimum embedment. Clean
the hole or continue drilling additional depth
to accommodate drill fines. Use a carbide drill
bit.
2) Assemble the washer and nut flush with the
end of anchor to protect threads. Drive the
anchor through the material to be fastened
until the washer is flush with the surface
material.
3) Expand the anchor by tightening the nut
3–5 turns past hand-tight position or to 34
newton meters of torque.
CAUTION
Always wear safety glasses and use other
necessary protective devices or apparel when
installing or working with anchors.
Anchors are not recommended for use in
lightweight masonry material such as block
or brick, or for use in new concrete which has
not had sufficient time to cure. The use of
core drills is not recommended to drill holes
for the anchors.
P O SI TI O N TH E U N I T
CAUTION
Protect any finished flooring before moving
the unit into place. All Built-In models are
equipped with rollers, so you can easily
move the unit into place.
Use an appliance dolly to move the unit near the
rough opening. Carefully move it off of the appli-
ance dolly. Each Built-In unit is equipped with
rollers, so it can be moved into position more
easily.
Shut off power to the electrical outlet. Plug the
power supply cord into the 15 amp grounded
outlet and roll the unit into position. Be sure that
the anti-tip bracket is properly engaged.
IMPORTANT NOTE: If possible, keep the door(s)
closed until the unit is properly anchored.
IMPORTANT NOTE: If for any reason the unit
has been laid on its back or side, you must allow
the unit to stand upright for a minimum of 24
hours before connecting power.
WARNING
To reduce the possibility of the unit tipping
forward, the front leveling legs must be in
contact with the floor.
WAT E R L I N E C O N N E C T I O N
Approximately .9 m of 6,35 mm plastic tubing is
connected to the unit with a preassembled 6,35
mm compression connection at the end. This
tubing is located under the unit.
The water line fitting connection kit, provided
with the unit, contains a 6,35 mm compression
union fitting for connection to the household
water line. Place the compression nut and sleeve
on the water line and fasten to the connection at
the end of the tubing under the unit. Do not over
tighten. Check all water line fittings for leaks.
Make sure that the drain pan can be installed or
removed without any water line interference.
IMPORTANT NOTE: Be sure to purge the water
line prior to final connection to the unit. This will
remove any debris that may be present in the
tubing from installing the new water line.
IMPORTANT NOTE: Let your customer know
that the ice maker will not produce ice immedi-
ately, and that the first few batches of ice
produced should be discarded. Allow 24 hours
for proper ice production.
IMPORTANT NOTE: Caution must be taken not
to expose the refrigerator, and/or water lines
leading to the refrigerator, to freezing tempera-
tures. Failure to do so could cause damage to
the product and home.
IMPORTANT NOTE: This appliance should be
connected to a potable water supply.
