B U ILT-IN INSTALLAT ION SPEC IF IC AT ION S
O V E R A LL D IME N S IO NS
Over-and-Under Models
Model ICBBI-30U
W H D
762 mm 2134 mm 610 mm
Model ICBBI-30UG
with Glass Door
W H D
762 mm 2134 mm 610 mm
Model ICBBI-36U
W H D
914 mm 2134 mm 610 mm
Model ICBBI-36UG with Glass Door
W H D
762 mm
914 mm 2134 mm 610 mm
Model ICBBI-30U
Unit dimensions may vary by ± 3 mm.
D O O R CLE A R A NC E
Over-and-Under Models
A
Model ICBBI-30U 794 mm
806 mm Flush Inset
Model ICBBI-30UG 794 mm
806 mm Flush Inset
Model ICBBI-36U 946 mm
959 mm Flush Inset
Model ICBBI-36UG 946 mm
914 mm
959 mm Flush Inset
Model ICBBI-36U
Door clearance is based on stainless
Stainless steel design shown.
steel door and handle dimensions.
606 mm
BEHIND
FRAME
A
WIDTH
OF UNIT
2134 2134
mm mm
762 mm 610 mm
Model ICBBI-30UG
2134
2134
mm mm
914 mm 610 mm
Model ICBBI-36UG
I NS TA LL A T IO N S P EC I FI C A TI O N S
* ANTI-TIP BRACKET MUST NOT
Over-and-Under Models— INTERFERE WITH WATER LINE.
REFER TO INSTALLATION
Overlay (non-flush inset) and Stainless Steel
INSTRUCTIONS FOR COMPLETE
DETAILS.
EXTEND WATER LINE APPROX
A
914 mm FROM BACK WALL.
Model ICBBI-30U 749 mm
Model ICBBI-30UG 749 mm
Model ICBBI-36U 902 mm
Model ICBBI-36UG 902 mm
Dimensions are for finished rough openings.
I NS TA LL A T IO N S P EC I FI C A TI O N S
* ANTI-TIP BRACKET MUST NOT
Over-and-Under Models— INTERFERE WITH WATER LINE.
REFER TO INSTALLATION
Flush Inset Application
INSTRUCTIONS FOR COMPLETE
DETAILS.
**ASSUMES 19 mm PANEL
A B THICKNESS.
EXTEND WATER LINE APPROX
Model ICBBI-30U 749 mm 813 mm
914 mm FROM BACK WALL.
Model ICBBI-30UG 749 mm 813 mm
Model ICBBI-36U 902 mm 965 mm
Model ICBBI-36UG 902 mm 965 mm
FLUSH INSET
Dimensions are for finished rough openings.
457 mm *
TOP VIEW
13 mm
WATER LINE
610 mm
OPENING
OUTLINE OF
DEPTH
OVERLAY
OR STAINLESS SHUT-OFF
STEEL MODEL VALVE
178
mm
LOCATE
610 mm
ELECTRICAL
OPENING WITHIN
DEPTH SHADED AREA
A
OPENING WIDTH
2127 mm
OPENING
HEIGHT
LOCATE WATER SUPPLY
WITHIN SHADED AREA
457 mm
76 mm
W
SIDE VIEW FRONT VIEW
457 mm *
TOP VIEW
13 mm
WATER LINE
610 mm
OPENING
OUTLINE
DEPTH
OF FLUSH INSET
APPLICATION WITH SHUT-OFF
19 mm PANEL VALVE
6 mm
56 mm **
178
610 mm
LOCATE mm
OPENING ELECTRICAL
DEPTH
WITHIN
56
mm ** SHADED AREA
FLUSH INSET
665 mm
DETAIL
DEPTH
6
mm
56
mm
610 mm
OPENING
2127 mm 2134
DEPTH
mm
OPENING
32
FLUSH
HEIGHT
mm
INSET
HEIGHT
A
32
OPENING WIDTH
mm
B
FLUSH INSET WIDTH
LOCATE WATER SUPPLY
WITHIN SHADED AREA
457 mm
76 mm
W
SIDE VIEW FRONT VIEW
152
mm
E
152
mm
1918 mm
152
mm
152
mm
665 mm
FLUSH INSET
DEPTH
E
152
mm
1918 mm
32
mm
152
mm
