TeraStation 4000
User Manual
www.buffalotech.com
35020039-03
2013-11

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TeraStation TS4800D and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Buffalo TeraStation TS4800D

Summary of Contents for Buffalo TeraStation TS4800D

  • Page 1 TeraStation 4000 User Manual www.buffalotech.com 35020039-03 2013-11...

  • Page 2: Table Of Contents

    Contents Chapter 1 Installation ............9 Diagrams ....................9 Installation ..................11 Turning the TeraStation On and Off..........14 Changing the Administrator Password ..........15 Recovery Drive ...................16 For Initializing Settings ................17 For Password Resetting ................17 Chapter 2 Configuration ..........18 Opening Settings ................18 Opening Easy Admin .................19 Chapter 3 Access Restrictions .........21 Configuring Access Restrictions on Users and Groups ....21 Adding a Shared Folder ................21...
  • Page 3 Chapter 4 Managing your Storage .........34 RAID Arrays ..................34 Working with RAID Arrays ..............35 Using JBOD ....................35 Changing RAID Mode ...................36 Configuring a Hot Spare ................37 RMM (RAID Mode Manager) .................38 RAID Scanning....................40 Adding an External Hard Drive ............41 Dismounting Drives ................41 Checking Drives .................42 Formatting Drives ................43 Encrypting Drives ................44...
  • Page 4 Hard Drive Replacement Examples .............61 Chapter 5 Backup ............67 Back Up from the TeraStation ............67 Preparing a Backup Destination ..............67 Configuring a Backup Job ................69 Replication ..................72 Failover ....................74 Ethernet Cable Connection Methods ............74 Configuring Failover ..................75 Backing Up Your Mac with Time Machine ........77 Copying from a USB Device ...............80 Amazon S3 ..................81 Chapter 6 Remote Access ..........83...
  • Page 5 Chapter 8 Multimedia .............92 DLNA ....................92 Configuration ....................92 Playing Files ....................94 Connected DLNA-compatible Devices ............94 Streaming to DLNA-compatible Devices ............95 Disabling Playback from Specific Devices ..........95 iTunes Server ..................96 Squeezebox Server ................97 Chapter 9 Advanced Features ........100 Antivirus Software ................100 Licenses ......................
  • Page 6 Connecting a Printer ............... 112 Setting Up a Printer with Windows 8, Windows 7, or Windows Vista ..112 Setting Up a Printer with Windows XP ............. 113 TeraSearch ..................114 Offline Files ..................115 DFS ....................118 Accessing from a NFS Client ............119 Encrypting Data Transmission ............
  • Page 7 Updating the Firmware ..............130 Name, Date, Time, and Language ..........131 Beep Alerts ..................132 LCD and LEDs ................... 133 Jumbo Frames ................. 134 Changing the IP Address ..............135 Chapter 10 Utilities ............136 NAS Navigator2 for Windows ............136 Mount as Network Drive................
  • Page 8 Environmental Information ..............149 KC ........................ 149 BSMI ......................149 CCC ......................150 电池警告语......................150 Models ......................150...

  • Page 9: Chapter 1 Installation

    Chapter 1 Installation Diagrams TS4800D TS4400D TS4400R...
  • Page 10 TS4200D Power Button To power on, connect the power cable and wait for 10 seconds, then press the power button. To power off, press the power button twice. Info LED If there is a status message, the amber info LEDwill light up. Check the LCD panel to see the status message. Error LED If there is an error, the red error LED will light up.

  • Page 11: Installation

    Compatible Buffalo USB 3.0 hard drives can be connected. USB hubs are not supported. USB 2.0 Port Compatible Buffalo USB hard drives, USB flash drives, digital cameras, and USB UPS connection can be connected. USB hubs are not supported. LAN Port 1 Use an Ethernet cable to connect this port to your network.
  • Page 12 Follow the steps on the screen to connect the TeraStation’s Ethernet and power cables and turn it on. Note: Use LAN port 1 for initial setup. After setup, you may connect a second cable to LAN port 2. If you use LAN port 2, configure the IP address at Network - IP Address in Settings.
  • Page 13 Clocks for the network devices may run at slightly different speeds. If these devices get out of sync it may cause network problems. • Buffalo is not responsible for any losses and damages incurred from using the ntp.jst.mfeed.ad.jp service or ser- vice outages.

  • Page 14: Turning The Terastation On And Off

    In NAS Navigator2, double-click your TeraStation’s icon. This will open the shared folder of the TeraStation. For Mac OS, the TeraStation is mounted as a drive icon on the desktop or it is displayed in the sidebar of the Finder. You can now use the TeraStation’s shared folder to save files just like any other folder.

  • Page 15: Changing The Administrator Password

    Note: The default username and password are “admin” and “password”. Settings will open. Click at the top-right of Settings and choose either Restart or Shut Down. When all the LEDs on the front of the TeraStation turn off, the shutdown process is complete. Changing the Administrator Password After initial setup, follow this procedure to change your password.

  • Page 16: Recovery Drive

    down the control key, then select Settings. Enter your username and password. Click Change Password. Enter the new password (twice). Click OK. You have changed the admin password. Recovery Drive To initialize all of the TeraStation’s settings, or just restore the admin password to its factory default value, create the...

  • Page 17: For Initializing Settings

    recovery drives as described below. For Initializing Settings A system initialization drive can reset all settings to their default values. Notes: • Normally, making and using the system initialization drive will not affect data. However, always back up your data regularly! •...

  • Page 18: Chapter 2 Configuration

    Chapter 2 Configuration Configure and administer your TeraStation using the Settings interface, accessible from a browser window. Open the interface using the procedure below or type the TeraStation’s IP address in the URL field of your browser.Within Settings, the Easy Admin page gives you quick access to commonly used settings. Note: Internet Explorer 9, Firefox 8, Google Chrome 15, Safari 5, and later are supported.

  • Page 19: Opening Easy Admin

    Username Password Settings Available admin password TeraStation name, IP address, workgroup, drive guest blank status, hardware version TeraStation’s name, IP address, workgroup, drive your username your password status, firmware version, and your password. Notes: • If the time-out period is set to “10 minutes”, you will be logged out of Settings after 10 minutes of inactivity. •...
  • Page 20 Click Easy Admin. The Easy Admin screen will open. Notes: • If you click any buttons , you will need to enter a username and password. • You can open Easy Admin anytime by clicking the icon at the top left of Settings.

  • Page 21: Chapter 3 Access Restrictions

    Chapter 3 Access Restrictions You may restrict access to specific shared folders, including external USB drives. Notes: • Access restrictions can be set separately for each shared folder, but not for folders within the shared folders. • Configure access restrictions through Settings. Configuring access restrictions through Windows is not supported and may cause unexpected behavior.
  • Page 22 Notes: • Names may contain up to 27 alphanumeric characters, hyphens (-), and underscores (_). Do not use a symbol as the first character in a name. • The description may contain up to 75 alphanumeric characters, hyphens (-), underscores (_), and spaces. Do not use a symbol or space as the first character.

  • Page 23: Adding Users

    Read-only Shares By default, new shares are set with read & write access, but you may change the attribute to Read-only in Shared Folder Attributes. Read-only shares and HFS+ formatted USB hard drives will have “Read-only” added to the shared folder description.

  • Page 24: Adding Groups

    • The description may contain up to 75 alphanumeric characters, hyphens (-), underscores (_), and spaces. Do not use a symbol or space as the first character. • When setting users with access privileges, a maximum of 300 users, including “admin” and “guest”, can be regis- tered in the TeraStation.

  • Page 25: Access Restrictions

    Notes: • Group names may contain up to 20 alphanumeric characters, hyphens (-), underscores (_), and periods (.). Do not use a symbol other than an underscore (_) as the first character. • Group descriptions may contain up to 75 alphanumeric characters, hyphens (-), underscores (_), and spaces. Do not use a symbol or space as the first character.
  • Page 26 Click Edit. Enable “Access Restrictions”. Select the level of access for the user or group you added. : Read and write access allowed Read access allowed : Access prohibited Click OK. Notes • The example above shows access restriction by user. To restrict access by group, click Local Groups tab and select group permissions.

  • Page 27: Active Directory

    • Configure hidden and read-only file attributes in Settings. Configuring them from within Windows is not supported and may cause unexpected behavior. • Folder and workgroup names whose names contain non-Roman characters may not be displayed correctly. • If shared folders are accessed from a Macintosh, information files for the Macintosh may be generated automatically. Do not delete these files.
  • Page 28 Click Yes. Enter the desired settings, then click OK. Choose Folder Setup. Click a shared folder that you want to set access restrictions for. Click Edit. Enable “Access Restrictions”. Select the level of access for the user or group. : Read and write access allowed : Read access allowed : Access prohibited Notes:...

  • Page 29: Nt Domains

    • To use the TeraStation as a member server in an Active Directory domain, the TeraStation should be logged in to the domain and accessed from a computer that is not a member of the domain with a valid domain account. •...
  • Page 30 Click to the right of “Folder Setup”. Click a shared folder for which you want to set access restrictions. Click Edit. Enable “Access Restrictions”. Select the level of access for “Domain Users” or “Domain Groups” you added. : Read and write access allowed : Read access allowed : Access prohibited Click OK.

  • Page 31: Delegating Authority To An External Smb Server

    • If the TeraStation has joined a domain network, you cannot connect to it via FTP. • Don’t disable the SMB protocol while an NT domain server is used for access restrictions. If you do, you will need to enable SMB again and reconfigure the NT domain settings from scratch. Delegating Authority to an External SMB Server TeraStations on your network can be linked to an authentication server for centralized management of user accounts and passwords.
  • Page 32 A shared folder for authentication will be created on the TeraStation. Users registered to the specified authentication server are automatically registered as users on the TeraStation when they open the shared folder for authentication. You can also register users directly. Connect to the authentication folder via SMB, not FTP or AFP.
  • Page 33 cally, select that user and click Delete External User. • When connecting through AFP or FTP, always use an IP address. Using a server name may cause problems with authentication. • To specify a server from another subnet, enter its IP address. •...

  • Page 34: Chapter 4 Managing Your Storage

    Chapter 4 Managing your Storage RAID Arrays TeraStations support many types of RAID. The type of RAID arrays available for use depends on how many drives are installed in your TeraStation. Notes: • If you change the RAID mode, all data on the array is deleted. This is true for every procedure in this chapter. Always back up any important data before performing actions that affect your RAID.

  • Page 35: Working With Raid Arrays

    RAID 50 RAID 50 arrays are available for TeraStations with 8 hard drives. In this mode, two RAID 5 arrays are combined into a RAID 0 array. The total usable space for 6 drives in a RAID 50 array is equal to 6 x the capacity of the smallest drive. RAID 10 RAID 10 arrays are available for TeraStations with 4 or more hard drives.

  • Page 36: Changing Raid Mode

    Click Delete RAID Array. Once JBOD mode is configured, create shared folders on each drive to use them. Changing RAID Mode To change the RAID mode, first put the drives in JBOD. Select RAID. Click the array to delete. Note: If the “RAID Mode” field is blank, the array is already in JBOD. Proceed to step 7. Click Delete RAID Array.

  • Page 37: Configuring A Hot Spare

    Note: Normally, after a RAID array is created, it is “resynced”, which optimizes the array, making it more stable. The resyncing process takes about 1 hour per terabyte of space in the array. File transfers will be slower during this period, but the array will remain fully usable.

  • Page 38: Rmm (Raid Mode Manager)

    Click Set as a hot spare. Step through the wizard. When the “Confirm Operation” screen opens, enter the confirmation number and click OK. Notes: • To turn the hot spare back into a normal disk, choose Set as a normal disk. •...
  • Page 39 Select the drive on which you do not want to erase data. Check “Add a disk to RAID array with RMM. Your data will be preserved. ” . Select the drive to add to the RAID array. Click Create RAID Array. The “Confirm Operation” screen will open. Enter the confirmation number, then click OK.

  • Page 40: Raid Scanning

    Changing the RAID mode while adding a drive: Select the drive you want to add to the RAID array and choose the mode for the array. Enter the “Confirm Operation” number and click OK. RAID Scanning RAID maintenance scans your RAID array for bad sectors and if it finds any it automatically repairs them. RAID 1, RAID 10, RAID 5 and RAID 6 arrays are supported.

  • Page 41: Adding An External Hard Drive

    • Digital cameras • USB-connected UPSs • USB printers Buffalo external USB drives are recommended. These devices are not supported: • DUB and DIU series drives • Hubs, mice, and keyboards Connect only one device to each USB port of the TeraStation. Some external drives with automatic power-on don’t turn on automatically when connected to the TeraStation.

  • Page 42: Checking Drives

    remounted. Dismounting from Settings In Settings, click Drives. Select Drives to dismount an internal drive or USB drives to dismount an external drive. Select the drive to dismount and click Dismount Disk. When the following message is displayed, it is safe to unplug the drive. Note: To remount the drive, unplug it and then plug it back in.

  • Page 43: Formatting Drives

    Select the drive to test, then click Check Disk. Click Check. You have the option of deleting information files from Mac OS during the check if desired. Formatting Drives Note: Under some circumstances, data deleted when a drive is formatted can be recovered. To ensure that data is “gone forever”, a format might not be sufficient.See “Erase Data on the TeraStation Completely”.

  • Page 44: Encrypting Drives

    The “Confirm Operation” screen will open. Enter the displayed number, then click OK. Depending on the size of your drive, the format may take several minutes or several hours to complete. “Formatting” will be displayed on the LCD display until the format is complete. Notes: •...

  • Page 45: Media Cartridges

    Media Cartridges If configured as a media cartridge, an internal drive can be used as a removable storage device in the same way as an external drive. Media cartridges can be unplugged and connected to a different TeraStation with all data intact. To configure a drive as a media cartridge, check “Media Cartridge”...

  • Page 46: Disk Quotas

    • An empty shared folder on each drive • All settings returned to their default values • All logs deleted If you remove a drive and then erase all data on the TeraStation, the LCD will show the error “HDx Error E22 HDx Can’t Mount”...

  • Page 47: Quotas For Users

    media cartridges. • If both user and group quotas are configured for a user, the most restrictive quota will always apply. Quotas for Users Follow this procedure to limit the shared folder disk space available for a user. In Settings, click to the right of “Users”.

  • Page 48: Size Limits

    Change the user’s primary group to the group with the quota, then click OK. Click Close. Size Limits If LVM is enabled,volumes can be created with maximum size limits. In Settings, click Drives. Select LVM. Select the drive or array where the volume will be located and click Enable LVM on Volume. The “Confirm Operation”...
  • Page 49 Configure the desired settings, then click OK. Click OK. Click Close. Click Close. Navigate to File Sharing - Folder Setup. Click Create Folder. Configure the settings.

  • Page 50: Using The Terastation As An Iscsi Device

    Notes: • The name may contain up to 27 alphanumeric characters, hyphens (-), and underscores (_). Do not use a symbol as the first character. • The description may contain up to 75 alphanumeric characters, hyphens (-), underscores (_), and spaces. Do not use a symbol or space as the first character.

  • Page 51: Network Configuration

    Differences Between NAS and iSCSI With iSCSI, the TeraStation is connected to a single computer such as a server. Other computers on the network access files on the TeraStation through the computer it’s connected to. The TeraStation can be used as a local drive from Windows Server.
  • Page 52 (1) Install the iSCSI Connection Tool on your computer from the CD supplied with the TeraStation, or download it from www.buffalotech.com. (2) Click Start - All Programs - BUFFALO - iSCSI Connection Tool - iSCSI Connection Tool. For Windows 8, click the iSCSI Connection Tool.
  • Page 53 Notes: • If you will use the TeraStation regularly, check “Connect on Start Up” before connecting. • Always disconnect the volume before shutting down the TeraStation. For the iSCSI Initiator included with Windows 8, Windows 7, Windows Vista, and Windows Server 2008: (1) Navigate to Control Panel - Administrative Tools - iSCSI Initiator.

  • Page 54: Using The Iscsi Connection Tool

    Create multiple LVM volumes, then create multiple iSCSI volumes. You can create up to 32 volumes. Download and install the iSCSI Connection Tool from www.buffalotech.com. Launch the tool at Start - All Programs - BUFFALO - iSCSI Connection Tool - iSCSI Connection Tool. For Windows 8, click the iSCSI Connection Tool.
  • Page 55 Select the TeraStation from the Target product list, then click Register iSCSI Device. Note: If access restrictions are configured, enter your username and password. Select the volume to be connected and click Connect. The connected volume is added as a local drive in Computer (or My Computer). Repeat these steps on each computer to connect multiple volumes.
  • Page 56 Disconnecting and Unregistering the TeraStation To disconnect the TeraStation, disconnect the volume and remove the registration as shown below. Click Start - All Programs - BUFFALO - iSCSI Connection Tool - iSCSI Connection Tool. For Windows 8, click the iSCSI Connection Tool.

  • Page 57: Creating And Expanding Volumes

    registration from each computer. Disconnect the Ethernet cable of the TeraStation. The TeraStation is now disconnected. Note: To disconnect multiple volumes in a single operation, follow the procedure below. (1) Start the iSCSI Connection Tool. (2) Click Setup - Remove the registered iSCSI Hard Disk. (3) Select the IP address (port number) of each TeraStation that you want to disconnect and click Remove.

  • Page 58: Setting Access Restrictions

    Click the volume you want to expand. Enter a new size and click OK. Click OK. Click Close. Setting Access Restrictions A username and password can be set following the procedure below for the entire TeraStation iSCSI volume or for each volume.
  • Page 59 Note: To use mutual authentication with access restrictions, configure the settings: • In the screen shown above, check “Mutual Authentication” and enter the password in the “Mutual Authentication Password” field. • In the “User Authorization” window displayed when the TeraStation is connected, select “Enable Mutual Authenti- cation”...

  • Page 60: Hard Drive Replacement

    Mutual Authentication Access Restrictions by Username and Password To set access restrictions using mutual authentication in addition to regular access restrictions, configure the settings as shown below. • In the screen above, check “Mutual Authentication” and enter the password in the “Mutual Authentication Password” field.

  • Page 61: Hard Drive Replacement Examples

    If you remove the drive without properly dismounting it, data may be lost or the TeraStation may malfunction. • Use a Buffalo OP-HDS series drive of the same size or larger for the replacement drive. If a larger drive is used, the extra space will not be usable in a RAID array.
  • Page 62 Hard drives without red status LEDs lit are still on. Do not unplug or remove them. Pull out the drive cartridge and remove it from the TeraStation.
  • Page 63 Insert the new drive in the empty slot. Slide the drive in with the locking mechanism open. Swing the lock back down until it clicks into place.
  • Page 64 When the replacement hard drive is recognized, the status LED will flash red and the message “Press FuncSW I31 New Disk x ready” will be displayed on the LCD panel. Hold down the function button on the front of the TeraStation for 3 seconds until it beeps. For RAID 1, 5, or 6: The TeraStation will start rebuilding the RAID array automatically.
  • Page 65 Hold down the function button on the front of the TeraStation for 3 seconds until it beeps. The TeraStation will start rebuilding the RAID array automatically. It takes about 5 minutes before the message “RAID I18 ARRAYx Rebuilding” is displayed. For RAID 51 or RAID 61: The TeraStation will start rebuilding the RAID array automatically.
  • Page 66 Open the front cover with the included key. The failed drive’s status LED will be glowing red. Push its unlock button and swing the lock mechanism out. Pull out the drive cartridge and remove it from the TeraStation. Insert the new drive in the empty slot. Slide the drive in with the locking mechanism open. Swing the lock back down until it clicks into place.

  • Page 67: Chapter 5 Backup

    Chapter 5 Backup Back Up from the TeraStation You can back up TeraStation folders to: • A different folder on the TeraStation • Another LinkStation on the network • Another TeraStation on the network You can also configure backup jobs from Easy Admin. Preparing a Backup Destination First, configure a folder as a backup destination.
  • Page 68 Note: To configure a password, enter it in the “Remote Backup Password” field. Leave this field blank if you don’t want a password. If the target device is configured with a backup password, you can easily find the backup target folder during configuration of the backup job by searching for the password.

  • Page 69: Configuring A Backup Job

    Click Add, enter the IP address of the target LinkStation or TeraStation, and click Close. If your setup meets the requirements below, you don’t have to configure these settings: • The source and target TeraStations are on the same network. •...
  • Page 70 Click Create New Job. Note: Up to 8 backup jobs can be configured. Select backup settings such as date and time to run. The following types of backup jobs may be selected: Type Files included Normal Backup All files in the source will be backed up to the destination. The first time the backup job runs like a normal backup.
  • Page 71 Click Browse under “Backup Source Folder Name”. Select the shared folder that will be the backup source, then click OK. Note: If you will use the same folder for both Amazon S3 remote replication and as a backup target folder, create a new subfolder under “\wbfs\amazons3”.

  • Page 72: Replication

    ment Backup”. • Options: “Ignore backup errors and continue backup job on schedule” should be selected. Make sure that “Over- write unchanged files” is not checked. Replication Replication copies all data from a share to a share on a different TeraStation. This is an easy way to configure a reliable system to provide data protection in the event your main TeraStation fails.
  • Page 73 Click Add under “Backup Target”. Select the shared folder that will be the replication target, then click OK. Click OK. Click Yes. Notes: • A maximum of 64 shared folders can be configured for replication. • Shared folders with a backup password set cannot be selected as replication targets. •...

  • Page 74: Failover

    “Run Differential Resync” will only copy data that does not exist at the replication target. • Don’t use the same TeraStation for both failover and replication, or replication and Time Machine. • Don’t configure replication from one source folder to multiple target folders. Failover With failover, two TeraStations are connected to the network for redundancy.

  • Page 75: Configuring Failover

    connecting their LAN 2 ports. Updating is done over this dedicated network path, so updates are quicker and don’t interfere with normal network traffic. With this setup, if the main TeraStation fails, the backup TeraStation will replace it by name, but will keep its original IP address. Connecting to the network at LAN port 1 and setting failover at LAN port 2 The main and backup TeraStations should be the same model and capacity.

  • Page 76: Network Problems

    Enter the administrator password of the target backup device, then click Start Failover. If the administrator password is correct, the backup TeraStation will beep. To accept the settings from the main TeraStation, hold down the function button on the front of the backup TeraStation until it stops beeping.

  • Page 77: Backing Up Your Mac With Time Machine

    able to detect the backup TeraStation on the network. Backing Up Your Mac with Time Machine Time Machine is a backup program included with OS X 10.5 or later. Configure your TeraStation as shown to use Time Machine. In Settings, move the AFP switch to the position to enable AFP.
  • Page 78 Click Backup. Click the icon to the right of “Time Machine”. Click Edit. Click Browse. Select the shared folder that you set in the previous step, then click OK. Click OK. Click OK. Move the Time Machine switch to the position to enable Time Machine.
  • Page 79 Click Choose Backup Disk. Select the TeraStation, then click Use for Backup. Enter a username and password with the rights to access the shared folder of the TeraStation, then click Connect. Note: If access restrictions are not configured on the target share, log in with the administrator account. The default username and password for the administrator account are “admin”...

  • Page 80: Copying From A Usb Device

    configured, log in with an account with write privileges. Time Machine will count down from 120 seconds, and the backup will begin. Copying from a USB Device Use Direct Copy to copy from a USB device directly to the TeraStation. Note: To use Direct Copy, connect only one USB device at a time.

  • Page 81: Amazon S3

    When the copy operation is finished, the access LED of the USB device will stop flashing. Hold down the function button for 6 seconds to dismount the device. The blue LED will go out and the and the device may be removed safely.
  • Page 82 Note: This folder is used by Amazon S3. Files are not added to the selected folder and the amount of used space does not increase. Enter the bucket name, access key ID, and secret access key of the Amazon S3 bucket, then click OK. Click Close.

  • Page 83: Chapter 6 Remote Access

    Chapter 6 Remote Access WebAccess WebAccess is a software program for accessing the files in the shared folder of your TeraStation from your computer, smartphone, or tablet through the Internet. Notes: • Be careful when configuring WebAccess. Certain settings can make the files in the shared folder available to any- one on the Internet, without any access restrictions.
  • Page 84 • You may use the default BuffaloNAS.com registration, or disable to use a different DNS server. • Choose a “BuffaloNAS.com name” and “BuffaloNAS.com key” for your WebAccess account. Names and keys may use 3 to 20 alphanumeric characters, underscores (_), and hyphens (-). •...
  • Page 85 Notes: • The following levels of security are available: “Allow Anonymous” - Anyone can access (view) shared folders. “Allow All Groups and Users” - All groups and users registered on the LinkStation or TeraStation can use WebAccess. “Use Inherited Folder Permissions” - Users and groups have the same access permissions with WebAccess that they do locally.

  • Page 86: Webaccess Remote

    • From a computer, supported browsers include Internet Explorer 8 and later, Firefox 3.6 and later, Safari 4 and later. Instructions: http://buffalonas.com/manual/en/ • Use compatibility mode to use WebAccess with Windows 8 in desktop mode. • To access from an iOS device, install the “WebAccess i” application from the App Store. Instructions: http://buffalonas.com/manual/i/en/ •...

  • Page 87: Ftp

    Click OK. Move the WebAccess Remote switch to the position to enable WebAccess Remote. You can directly access the shared folder in the remote TeraStation by entering the path displayed in Target Folder into the address box in Explorer, My Computer, or other file manager. Note: If using after the network has been temporarily disconnected, click Remount.
  • Page 88 Accessing the TeraStation with an FTP client: • To access the TeraStation via FTP, configure your FTP client software with the following settings: Hostname: IP address of the TeraStation Username: The TeraStation’s username Password: The TeraStation’s password Port: 21 • Shared folders connected by FTP are available from the “/mnt”...
  • Page 89 /mnt/usbdisk1 /mnt/usbdisk2 Accessing the TeraStation with an Anonymous user: • To allow anonymous access to your FTP share, disable access restrictions. • To access the TeraStation via anonymous FTP, configure your FTP client software with the following settings: Hostname: IP address of the TeraStation Username: anonymous Password: any character string Port: 21...

  • Page 90: Chapter 7 Bittorrent

    Chapter 7 BitTorrent BitTorrent is a protocol for distributing large amounts of data efficiently. The information in this chapter is for users who are familiar with BitTorrent. Note: Use compatibility mode to use Download Manager with Windows 8. Configuration In Settings, click Applications. Click the icon to the right of “BitTorrent”.
  • Page 91 Click OK. Move the BitTorrent switch to the position to enable BitTorrent. Click the icon to the right of “BitTorrent”. Click Open Download Manager. The default username is “admin” and the default password is blank (no password). The download manager will open.

  • Page 92: Chapter 8 Multimedia

    Chapter 8 Multimedia DLNA DLNA is a set of guidelines for sharing digital media. The TeraStation includes a DLNA server compliant with the DLNA guidelines. The movies, photos, and music saved on this product can be played back on DLNA-compliant TVs, stereo equipment, game consoles, and other devices within the network.
  • Page 93 Click Services. Move the DLNA switch to the position to enable DLNA. Click the icon to the right of “DLNA Server”. Click Edit. Select an interval for DLNA server database updates and click OK.

  • Page 94: Playing Files

    Playing Files To play back content from a DLNA-compatible device: Connect the DLNA-compatible device to the same network as the TeraStation and turn it on. Select the TeraStation in the software of the DLNA-compatible device. Select the content to be played back. Connected DLNA-compatible Devices Follow the procedure below to view the DLNA-compatible devices connected to your TeraStation.

  • Page 95: Streaming To Dlna-Compatible Devices

    Streaming to DLNA-compatible Devices When new movies, photos, and music files are added to the TeraStation’s DLNA folder, the database must be updated before the new file can be streamed.By default, the database is updated at startup and again every 60 minutes. You can change this interval or update the database manually.

  • Page 96: Itunes Server

    Uncheck the devices you do not want to allow to play media and click OK. Supported File Types The TeraStation supports DLNA streaming of files with the extensions below. Types File Extensions .avi, .divx, .asf, .mpg, .mpe, .m1v, .vob, .mts, .m2ts, .m2t, .mpeg, .mpeg2, .vdr, .spts, .tp, .ts, .3gp, Video files .mov, .m4v, .wmv, .dvr-ms, .xvid, .mp4, .m4v Picture files...

  • Page 97: Squeezebox Server

    Click Edit. Click Browse. Select the shared folder that you want to make available to iTunes, then click OK. Click OK, then OK again. Move the iTunes server switch to the position. Squeezebox Server Squeezebox is a network music player by Logitech that can play back music stored on your network using your wired or wireless LAN without a computer.
  • Page 98 Configuration In Settings, click Services. Move the Squeezebox server switch to the position to enable Squeezebox server. Click to the right of “Squeezebox Server”. Click Edit. Click Browse. Select the shared folder that you want to make available to Squeezebox, then click OK. Enter port number (9001 is recommended), then click OK.
  • Page 99 Click OK. Click Open Squeezebox. The Squeezebox’s settings will open.

  • Page 100: Chapter 9 Advanced Features

    Chapter 9 Advanced Features Antivirus Software Trend Micro NAS Security can protect your network and data from software viruses, malware, and spyware. To use Trend Micro NAS software, purchase an OP-TSVC license pack (sold separately). If your TeraStation includes activated antivirus software, no license registration is necessary.

  • Page 101: Activating Virus Scanning

    Activating Virus Scanning Follow the procedure below to activate virus scanning. In Settings, click Applications. Move the antivirus switch to the position. A quarantine folder named “TMNAS” is automatically created on the TeraStation. If a virus is detected, viruses are moved to this folder.

  • Page 102: Connecting Through A Proxy Server

    You can log on with the TeraStation’s admin account. The default username and password are “admin” and “password”. Trend Micro NAS Security settings will open. Connecting through a Proxy Server If you must pass through a proxy server to connect to the Internet in your network environment, follow this procedure to set the IP address of the proxy server and other settings.

  • Page 103: Excluding A Specific Folder From Antivirus Scanning

    From the left-side menu, choose Scheduled Updates. Check “Enable Scheduled Update”. Select a time for updates to begin, an interval for updates, and an amount of time for updates to continue. Select the components to update. Click Save. The antivirus software is now configured to update automatically at the scheduled time. Updates will not be downloaded if the TeraStation is turned off, in standby mode, or disconnected from the Internet.

  • Page 104: Virus Scanning

    Virus Scanning Three types of virus scans are available: Real-time Scan The virus scan runs in the background, scanning every file that you read or write. This is the default type of scanning. Your TeraStation may run slower if real-time scanning is enabled. Scheduled Scan A scheduled scan is executed at specific regular intervals, such as every Tuesday at 3 am.

  • Page 105: Checking The Log

    This starts the virus scan. If the scan finds a virus, the user can be notified in two ways: • The message “Virus alert I34” is normally shown on the LCD panel. Once the virus is removed from the quarantine folder, the message is no longer displayed.

  • Page 106: Online Help

    This completes the procedure for checking the log. Online Help For more information on the antivirus software, refer to the online help. Follow the procedure below to access the online help. From the right-top menu, choose Help - Contents and Index. Online help will open.

  • Page 107: Sleep Mode

    Move the email notification switch to the position to enable email notification. Click to the right of “Email Notification”. Click Edit. Enter your mail server settings and choose what events will trigger notification. Click OK to send a test email. Sleep Mode To save energy, you can specify times to put the TeraStation into sleep (standby) mode, where the hard drive and LEDs are turned off.
  • Page 108 Notes: • Up to three timers can be set. • The time to enter sleep mode can be set from 0:00 to 27:45. The time to wake from sleep mode can be set from 0:00 to 23:45. If the time to enter sleep mode is after 24:00, the wake-up time setting may be from 4:00 to 23:45. 24:00 refers to 0:00 of the next day and 27:00 refers to 3:00 of the next day.

  • Page 109: Wake-On-Lan

    • On the local network, Wake-on-LAN packets may be sent to port 2304 on either of the TeraStation’s LAN ports. If the TeraStation is connected to a Buffalo wireless router configured for remote access, then it may be turned on from outside the local network (from the WAN side).

  • Page 110: Port Trunking

    Plug the power cable of the UPS to a wall socket. Connect the AC cable of the TeraStation to the UPS. Connect the UPS and TeraStation using a USB cable or serial cable. Turn on the UPS, then the TeraStation. In Settings, click Management.
  • Page 111 The port trunking modes that can be set in the TeraStation are shown below. Trunking Mode Characteristics Disabled Port trunking is not used. A round-robin policy is set for providing fault tolerance and load Round-robin balancing. Active-backup An active-backup policy is set for providing fault tolerance An XOR (exclusive-or) policy is set for providing fault tolerance and load balancing.

  • Page 112: Connecting A Printer

    Reboot the TeraStation before use. Connecting a Printer You can connect a printer to the USB port on the TeraStation. Notes: • Only one USB printer can be connected to the TeraStation. • Bidirectional communication is not supported i.e., remaining ink quantities and other printer status information is not supported.

  • Page 113: Setting Up A Printer With Windows Xp

    Select your printer, then click OK. Register the printer. Setting Up a Printer with Windows XP In Settings, click Services. Move the print server switch to the position to enable the print server. Refer to the manual supplied with the printer. Click Start - Control Panel.

  • Page 114: Terasearch

    Register the printer. TeraSearch TeraSearch lets you search for character strings contained in files (text files, Word files, etc.) stored on the TeraStation. Follow the steps below to enable it. Open Folder Setup. Click the shared folder to be indexed. Click Edit.

  • Page 115: Offline Files

    Move the TeraSearch switch to the position to enable TeraSearch. Click to the right of “TeraSearch”. Click Refresh Index Click Edit. Enter the port number that you want to use and the time that the index will be updated, then click OK. Open the following URL in your browser.
  • Page 116 Click the shared folder for offline files. Click Edit. Choose “Manual File Caching”, “Automatic File Caching”, or “Automatic Program and File Caching”, then click OK. Note: “Manual File Caching” - User selects files that are cached. “Automatic File Caching” - Opened files can be cached locally for offline use. Previous versions of files that are not synchronized are automatically replaced by the latest versions.
  • Page 117 Note: Offline files cannot be enabled if “Use Fast User Switching” is enabled. To change the setting, open “User Accounts” in Control Panel and select “Change the way users log on or off”. Right-click the icon of the shared folder on the TeraStation for which you have set the offline feature, then click Make Available Offline.

  • Page 118: Dfs

    following the instructions on the screen. DFS (Distributed File System) is a set of client and server services that allows Windows users to organize many distributed SMB file shares into a distributed file system. Follow the steps below to enable DFS on the TeraStation. Note: Don’t disable the SMB protocol while DFS is enabled.

  • Page 119: Accessing From A Nfs Client

    Accessing from a NFS Client Note: (US purchasers only) Buffalo’s customer support will help configure the NFS settings on your TeraStation, and will support VMware and Windows clients but will not provide support for configuring your Linux or other UNIX clients.
  • Page 120 Choose the shared folder that will be accessible to the NFS client. Click Edit. Under “LAN Protocol Support”, enable “NFS”. Click OK. Note the NFS path. It will be used later for accessing data from an NFS client. Click Close. Move the NFS switch to the position to enable NFS.

  • Page 121: Encrypting Data Transmission

    The mount command depends on your operating system. The examples below assume that IP address of your TeraStation is 192.168.11.10, “/mnt/array1/share” is the desired NFS path, and “/mnt/nas” or drive letter “z” is the mount point. For Linux: mount -t nfs 192.168.11.10:/mnt/array1/share /mnt/nas For Windows Service for Unix 3.5: mount 192.168.11.10:/mnt/array1/share z: For Solaris 10:...

  • Page 122: Ssl Keys

    The server certificate included in the TeraStation in the default settings was created by Buffalo Technology, and in some cases the message “There is a problem with this website’s security certificate” may be displayed in your browser or other software. Disregard this message and continue.

  • Page 123: Mysql Server

    Click Edit. Note: The settings of the PHP language interpreter can be changed from “Edit php.ini”. Click Browse. Choose a shared folder for the web server , then click OK. Choose an external port, then click OK. MySQL Server The TeraStation can be used as a MySQL server. A MySQL database may be installed and linked with the web server. The TeraStation uses version 5.0.70 of MySQL server and version 3.2.2 of PhpMyAdmin.

  • Page 124: Snmp

    SNMP If SNMP is enabled, you can browse your TeraStation from SNMP-compatible network management software. The specific MIB (management information base) file for Buffalo is available from the Buffalo website (buffalotech.com). In Settings, click Network. Move the SNMP switch to the...

  • Page 125: Saving And Applying Settings

    Click to the right of “SNMP”. Click Edit. Configure the desired settings, then click OK. Saving and Applying Settings The TeraStation’s settings can be saved to a USB memory device and restored to another TeraStation. Use this function to back up and copy settings to a new TeraStation. Make a note of the hard drive configuration (number of hard drives, RAID, LVM, etc.) of the TeraStation where the settings were saved.

  • Page 126: Applying Settings

    Click to the right of “Restore/Erase”. From “Target USB drive”, select the USB memory device that is connected to the USB 2.0 port of the TeraStation. Select “Save current configuration to a USB drive”, then click Execute. Troubleshooting: If the settings are not saved to the USB memory device successfully, you may receive the error message “The specified operation cannot be executed.

  • Page 127: Restoring Factory Defaults

    Select “Transfer settings from a USB drive”, then click Execute. Restoring Factory Defaults Initializing from Settings To initialize the TeraStation to its factory defaults from Settings, follow this procedure. In Settings, click Management. Click to the right of “Restore/Erase”. Click Initialize TeraStation. The “Confirm Operation”...

  • Page 128: Initializing With The Usb Drive

    In Settings, navigate to Management-Restore/Erase-USB Options. Select Create a USB drive for initializing settings. Note: All data on the USB flash drive will be erased! Select the USB memory device from “Target USB drive”, then click Execute. Enter the 4 digit confirmation number and click OK. The TeraStation will create the initialization drive. This will take about a minute.

  • Page 129: Resetting With The Usb Drive

    Note: All data on the USB flash drive will be erased! Select the USB memory device from “Target USB drive” list, then click Execute. Enter the 4 digit confirmation number and click OK. The TeraStation will create the password reset drive. This will take about a minute.

  • Page 130: Updating The Firmware

    The file operation log stores file operations performed on the internal hard drives. File operations on USB drives are not logged. To transfer logs Click Edit. Enable “Syslog Transfer”. Enter the IP address of the syslog server where you want to transfer the logs to. Select the type of log that you want to transfer from “Logs To Transfer”.

  • Page 131: Name, Date, Time, And Language

    Click Install Update. You can also download the firmware from www.buffalotech.com. Note: Settings is not available while the firmware is updating. Don’t try to access Settings from another computer until the update is complete. Name, Date, Time, and Language Configure the TeraStation’s hostname, date, time, and language as follows. Note: If the TeraStation is being used as an iSCSI hard drive, to change the settings, navigate to Drives - iSCSI in Settings and set the icon to In Settings, click Management.

  • Page 132: Beep Alerts

    Note: The internal clocks of the TeraStation and other devices on your network may run at slightly different speeds. Over a long period of time your network devices may show somewhat different times, which can cause network problems. If clocks on your network vary by more than 5 minutes it may cause unexpected behavior. For best results, keep all clocks on the network set to the same time by adjusting them regularly, or use an NTP server to correct them all automatically.

  • Page 133: Lcd And Leds

    Select the conditions to beep the alert, then click OK. LCD and LEDs You may configure the LEDs and LCD on the front of the TeraStation. In Settings, click Management. Click to the right of “Notifications”. Click Edit. Click Front Panel Display Settings. Configure your settings, then click OK.

  • Page 134: Jumbo Frames

    Jumbo Frames If your other network devices support it, you may be able to increase network performance with jumbo frames. In Settings, click Network. Click to the right of “IP Address”. Click the LAN port where the jumbo frames will be used. Click Edit.

  • Page 135: Changing The Ip Address

    Changing the IP Address Normally, the TeraStation’s IP address is set automatically from a DHCP server on your network. If you prefer, you can set it manually. An easy way to do this is to change it from NAS Navigator2 running on a computer connected to the same router (subnet) as the TeraStation.

  • Page 136: Chapter 10 Utilities

    Chapter 10 Utilities NAS Navigator2 for Windows NAS Navigator2 is a utility program that makes it easy to display Settings, change the TeraStation’s IP address, or check its hard drive. If you installed the TeraStation with the TeraNavigator CD, NAS Navigator2 was installed automatically. To launch NAS Navigator2, double-click the icon.
  • Page 137 Name Description Icons: Displays icon. View Details: Displays hostname, product name, workgroup, IP address, subnet mask, and default gateway. View Selects the sort order from following to display when multiple TeraStations are found: Sort by Hostname, product name, workgroup, IP address, subnet mask, default gateway Browse Opens the TeraStation’s shared folder.

  • Page 138: Mount As Network Drive

    Name Description Configuration Click Settings to open the configuration interface. Check Use DHCP to assign an IP address from the DHCP server automatically. If there is no DHCP server in the network, you cannot use this function. IP Address Check Renew IP address to obtain an IP address from the DHCP server. You can manually enter an IP address, subnet mask, and default gateway.

  • Page 139: Nas Navigator2 For Mac

    NAS Navigator2 for Mac NAS Navigator2 is a utility program that makes it easy to display Settings, change the TeraStation’s IP address, or check its hard drive. If you installed the TeraStation with the TeraNavigator CD, NAS Navigator2 was installed automatically. To launch it, click icon in the Dock.

  • Page 140: Mount As Network Drive

    The iSCSI Connection Tool is a Windows utility that lets you use the TeraStation as an iSCSI drive. To launch it,click Start - All Programs - BUFFALO - iSCSI Connection Tool - iSCSI Connection Tool. For Windows 8, click the iSCSI Connection Tool.

  • Page 141: Menu

    Name Description If a TeraStation is selected, clicking Register iSCSI Device will register all the volumes in the TeraStation to the computer for enabling connection to individual volumes. Target If a volume is already registered, click Unregister iSCSI Device to unregister all volumes, disconnecting them from the TeraStation.
  • Page 142 Configuration Opens Settings for the selected TeraStation. Change IP address You can change the IP address of the selected TeraStation. If you disconnect the TeraStation without unregistering it or changing its IP address, the registration information stays in your computer and Unregister iSCSI device searches will take longer.

  • Page 143: Chapter 11 Appendix

    Displays the date and time set in the TeraStation. 2012/1/1 11:11 Errors LCD Message Description Corrective Action Contact Buffalo technical support for BOOT FAIL Hard drive not found. assistance. SYSTEM Error E04 Contact Buffalo technical support for The firmware is corrupted.

  • Page 144: Status

    HDx Error E22 Mounting of hard drive X failed. replace the hard drive. If the error is displayed HDx Can’t Mount again, contact Buffalo technical support for assistance. In the main TeraStation’s settings, navigate to FailOver E27 Unable to find the backup TeraStation.
  • Page 145 In Settings, navigate to Backup - Replication and or synchronization between the Replication I33 choose “Resync” to execute resynchronization. If the main TeraStation and the backup error is displayed again, contact Buffalo technical ReplicateFailure TeraStation failed during failover support for assistance. configuration.
  • Page 146 Media cartridge cannot be decrypted. Cartridgex I36 The media cartridge may have been Connect to the TeraStation that performed encrypted by a TeraStation other than encryption to decrypt. Decryption error this product. Recovery I37 System recovery in progress. SystemRecovering Recovery I38 System recovery is complete.

  • Page 147: Default Settings

    Settings can only be restored for the TeraStation whose settings were originally saved. To restore settings, insert the USB memory device, move the Recovery I55 Authentication during recovery of Boot Mode switch on the rear of the TeraStation settings failed. RecoveryAuthFail to the USB position, and restart the TeraStation.
  • Page 148 UPS Port (D-SUB 9 pin (Male)) x 1 UPS Port Note: Compatible UPS are manufactured by Omron or APC. If a hard drive in the TeraStation malfunctions, replace it with a Buffalo OP-HDS series Internal Hard Drive drive of the same capacity, available from www.buffalotech.com.

  • Page 149: Compliance Information

    Compliance Information The TeraStation uses GPL code. For source code, visit http://opensource.buffalo.jp. FCC Warning This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.

  • Page 150: Models

    干擾, 在這種情況下, 使用者會被要求採取某些適當的對策。 声明: 此为A级产品，在生活环境中，该产品可能会造成无线电干扰。在这种情况下，可能需要用户对其干扰采取切实可 行的措施。 设备的最高使用室内环境温度: 35° C 仅适用于海拔 2000M 以下地区安全使用。 断开装置为电源软线上的插头。插座应当装在设备的附近，而且应当便于触及到。 电池警告语 1.电池不得暴露。 2.使用型号不正确的电池可能导致爆炸。 Models TS4200D, TS4400D, TS4800D, TS4400R...

This manual is also suitable for:

Terastation ts4200dTerastation ts4400dTerastation ts4400r

Table of Contents
