Danfoss CF-RC Instruction page 12

Instruction CF-RC Remote Controller
• Activate program (- 3) from the Options menu with OK to select the days for GB
this program:
Use the up/down and left/right selectors (fig. - / ) to select the days for
this program by moving them above the horizontal line. Confirm with OK, and
activate the next step to select the time for the setback program.
Select the time for the setback program by setting the times for the periods
during which you want a normal room temperature, indicated by the black
bars above the time line (the periods outside the black bars are the set-
back periods with reduced room temperature). Set the start and end times
by means of the left/right selector and by toggling between them using the
up/down selector (fig. - / ).
You can remove the second
period with the normal room
temperature by changing the
end time of this period to its
start time:
VI.UH.M4.1C Produced by Danfoss Floor Heating Hydronics 03.2007
