Summary of Contents for Danfoss IK2
- Page 1 User Manual Remote Controls IK2 Transmitters www.danfoss.com...
- Page 2 User Manual Remote Control IK2 Transmitters Revision history Table of revisions Date Changed May 2021 Added trouble shooting and start-up information for TR2400 0201 December 2018 Rebranded to Danfoss 0101 © Danfoss | May 2021 BC290862531428en-000201...
-
Page 3: Table Of Contents
User Manual Remote Control IK2 Transmitters Contents Safety instructions FCC rules......................................4 General safety....................................4 Safety warnings....................................5 Technical description IKx dimensions and identification..............................6 IK Transmitters Start up (400-900Mhz)............................. 7 IK Transmitters Start up (2.4 GHz)...............................8 IK2 Detailed description.................................9 Maintenance Maintenance tips....................................10 Troubleshooting (400-900 MHz)...............................10... -
Page 4: Safety Instructions
• Service the equipment periodically. • When carrying out repairs, use spare parts supplied by Danfoss only. Warning Potential damage to the operator or the product. Do not use this product on machines in potentially explosive atmospheres unless the model is ATEX/RATEX certified to work in such conditions. -
Page 5: Safety Warnings
Avoid knocking or dropping the product. • Do not use the product if a failure is detected. Changes or modifications not approved by Danfoss can void the user's authority to operate this product. Quick reference precautions © Danfoss | May 2021... -
Page 6: Technical Description
User Manual Remote Control IK2 Transmitters Technical description IKx dimensions and identification The illustration below details dimensions and highlights product components. Dimensions in mm 158.70 Label for crane identification Maneuver elements Multi-key or Key + START Button STOP button Optional: range limiter... -
Page 7: Ik Transmitters Start Up (400-900Mhz)
User Manual Remote Control IK2 Transmitters Technical description IK Transmitters Start up (400-900Mhz) Use the information below to properly turn the transmitter ON (OPERATION mode). 1. Place a charged battery in the transmitter. The charge must be done following the instructions of the Battery Chargers' Manual. -
Page 8: Ik Transmitters Start Up (2.4 Ghz)
User Manual Remote Control IK2 Transmitters Technical description IK Transmitters Start up (2.4 GHz) In order to turn the transmitter ON (OPERATION mode), please follow these steps: Start up the device 1. Place a charged battery in the transmitter. The battery must be charged following the instructions of the Battery Charger Manual. -
Page 9: Ik2 Detailed Description
User Manual Remote Control IK2 Transmitters Technical description IK2 Detailed description Description Value Stop Function (400 - 900 MHz) Cat. 3-PLd Stop Function (2.4 GHz) Cat3 - PLe Ingress Protection rating IP65/NEMA4 Anti-condensation system Goretex Film Frequency band - ERP 433.050 to 434.040 MHz;... -
Page 10: Maintenance
User Manual Remote Control IK2 Transmitters Maintenance IK2 maintenance tips This product is designed for use in an industrial environment that may shorten the product's lifespan. Use these tips to maximize the lifespan of the product. • Use the hook/belt provided with the transmitter to prevent the transmitter from falling •... - Page 11 User Manual Remote Control IK2 Transmitters Maintenance Color and frequency Pulse frequency Description Action Green | fast pulses Attempting to link with the receiver and waiting its Wait answer Green | continuous Working Operate Green | slow pulses Latency; no action has been taken for some time...
-
Page 12: Charger And Battery
User Manual Remote Control IK2 Transmitters Charger and battery Charger and battery Disposal note: This symbol on the product indicates that it may not be disposed of as household waste. It must be handed over to the applicable take-back scheme for the recycling of electrical equipment. -
Page 13: Bc70K Charger Leds Status
(keys, coins, etc.) • Always keep contacts clean • Caution! Risk of Explosion if Battery is Replaced by an incorrrect type. Non Danfoss Battery use may void warranty © Danfoss | May 2021 BC290862531428en-000201 | 13... -
Page 14: Bc70K Battery Charger Dimensions
User Manual Remote Control IK2 Transmitters Charger and battery BC70K Battery Charger Dimensions Dimensions (mm) 2.57 97.15 103.31 14 | © Danfoss | May 2021 BC290862531428en-000201... - Page 15 Phone: +86 21 2080 6201 Danfoss can accept no responsibility for possible errors in catalogues, brochures and other printed material. Danfoss reserves the right to alter its products without notice. This also applies to products already on order provided that such alterations can be made without subsequent changes being necessary in specifications already agreed.
