- Page 1 User Manual Remote Control MP08A Receiver www.danfoss.com...
- Page 2 User Manual MP08A Receiver Revision history Table of revisions Date Changed March 2022 Updated safety information 0201 January 2019 Rebranded to Danfoss Power Solutions 0101 © Danfoss | March 2022 BC292475492602en-000201...
-
Page 3: Table Of Contents
MP08A/MP08V detailed description............................7 Installation Receiver installation..................................8 Input and output configuration..............................9 Digital outputs..................................... 9 Analog outputs..................................10 Radio/manual option (exclusive to MP08A)........................10 Pinout information...................................11 Troubleshooting MP08 Receiver Faceplates................................12 400-900MHz Receiver LED troubleshooting........................12 2.4GHz Receiver LED troubleshooting........................... 13 ©... -
Page 4: Safety Instructions
• Service the equipment periodically. • When carrying out repairs, use spare parts supplied by Danfoss only. Warning Potential damage to the operator or the product. Do not use this product on machines in potentially explosive atmospheres unless the model is ATEX/RATEX certified to work in such conditions. -
Page 5: Safety Warnings
Avoid knocking or dropping the product. • Do not use the product if a failure is detected. Changes or modifications not approved by Danfoss can void the user's authority to operate this product. Quick reference precautions © Danfoss | March 2022... -
Page 6: Technical Description
118.73 1. Fixing slots (fixed assembly or anti-vibration) 2. DEUTSCH connector 3. External antenna 4. Removable internal EEPROM 5. RF Module 6. External signaling LEDs 7. DEUTSCH connector pinout 8. Analog input configuration jumpers © Danfoss | March 2022 BC292475492602en-000201... -
Page 7: Mp08A/Mp08V Detailed Description
User Manual MP08A Receiver Technical description MP08A/MP08V detailed description Technical data Specification MP08A MP08V Stop function (400-900 MHz) Cat. 3-PLd Stop function (2.4 GHz) Cat. 3-PLe Ingress protection IP65/NEMA4 Frequency band - ERP 433.050 to 434.040 MHz; ERP<1mW 434.040 to 434.790 MHz; ERP<10mW 869.700 to 870.000 MHz;... -
Page 8: Installation
User Manual MP08A Receiver Installation MP08A receiver installation The below information describes hazards to be aware of during installation and steps to locate the receiver. Risk of shock Completely shut down the machine when installing the receiver. Check the power supply and shut off the main switch to disconnect the interface cable between the receiver and the machine's electrical box. -
Page 9: Input And Output Configuration
The MP08 Receiver does have an current limitation of 7.5 Amps, however it does not include a Fuse. It is highly recommended to install an External fuse. MP08A digital outputs The digital output group K1-K4 have a common contact at pin B1 of the connector. This pin is connected to pin B12 (stop) for powering up the group of outputs. -
Page 10: Analog Outputs
The receiver has the possibility to connect to an external switch for changing from Radio mode to Manual mode if needed. Thus, all inputs and outputs of the receiver will be voided, except from the emergency stop output. This option is exclusive to MP08A. 10 | ©... -
Page 11: Pinout Information
User Manual MP08A Receiver Installation MP08A pinout information Below is a description of each pin in the connector. Connector A Description IN 0-10V / IN 0-20mA Manual Connector B PW / K1-4 1SA4 1SA3 1SA2 1SA1 1SA-1 1SA-2 1SA-3 1SA-4... -
Page 12: Troubleshooting
No radio signal detected LED on + transmitter switched Radio channel occupied Change transmitter's frequency channel LED on + DATA switched off Radio channel occupied by non Danfoss system Change transmitter's frequency channel DATA LED off + SINGAL LED on Radio error Replace radio Green;... -
Page 13: 2.4Ghz Receiver Led Troubleshooting
LEDs are not externally visible. The LEDs on the receiver board are POWER, STATUS, DIAG1, DIAG2, ORDER, RELAY, CANERR and CANRUN in that order. Please do check the following website for further information: https://troubleshooting.dps-rct.com/en/customer-service-center © Danfoss | March 2022 BC292475492602en-000201 | 13... - Page 14 Orange | 4 pulses Green | slow pulses Low link quality Green | double pulses Medium link quality Green | triple pulses High link quality DIAG2 NOT USED NOT USED NOT USED 14 | © Danfoss | March 2022 BC292475492602en-000201...
- Page 15 Green | fast pulses Pre operational Status, Receiver waiting for the Controller must send the controller. Operational code to the Receiver. Green | continuous Receiver connected to the CAN network and operational © Danfoss | March 2022 BC292475492602en-000201 | 15...
- Page 16 Phone: +86 21 2080 6201 Danfoss can accept no responsibility for possible errors in catalogues, brochures and other printed material. Danfoss reserves the right to alter its products without notice. This also applies to products already on order provided that such alterations can be made without subsequent changes being necessary in specifications already agreed.
