The standard feedback system has two vector input signals, r and d
three vector output signals, e, u, and y. It can therefore be described by the
3 2 block matrix that relates the three output vector signals to the two
input vector signals:
e
=
u
y
The entries of this block matrix, that is, the transfer functions from r and
d to e, u, and y, have standard names and interpretations (which agree
act
with the standard SISO notation):
• The sensitivity transfer function is denoted S and given by
–1
S = (I + PC) . The sensitivity transfer function is the transfer function
from reference input r to the error signal e.
• The closed-loop transfer function T is given by T = PC(I + PC)
the transfer function from r to y. T can be expressed in several other
ways, for example:
T PC I
=
• The actuator effort transfer function C(I + PC)
function from r to u, and so is related to the actuator effort required.
For example, its step response matrix shows the closed-loop step
responses from each reference input signal to each actuator signal.
• The transfer function from d
called the actuator-referred sensitivity transfer function. The
actuator-referred sensitivity transfer function determines the errors
generated by actuator-referred disturbances. It also can be expressed as
–1
(I + PC) P. Notice that it is "complementary" to the transfer function
described just above, that is, C(I + PC)
transfer functions can be obtained from each other by swapping P
and C.
• The transfer function from d
actuator-referred actuator effort transfer function. Notice that it is
related to the closed-loop transfer function by swapping P and C. It can
also be expressed as C(I + PC)
• The transfer function from d
called the actuator-referred closed-loop transfer function.
