Wireless External Alarm
Model: SA-001S
User's Instructions

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SA-001S and is the answer not in the manual?

Questions and answers

Related Manuals for SkyLink SA-001S

Summary of Contents for SkyLink SA-001S

  • Page 1 Wireless External Alarm Model: SA-001S User’s Instructions...

  • Page 2: Table Of Contents

    ERASE REMOTE OR SENSOR OR CONTROL PANEL FROM THE WIRELESS EXTERNAL ALARM ............ALARM SOUND DURATION ................ ARMING SEQUENCE ..................OPERATING THE SKYLINK SECURITY CONTROL PANEL ....10-11 CONNECT THE WIRELESS EXTERNAL ALARM WITH YOUR EXISTING ALARM SYSTEM ................. ALERT NOTIFICATION JUMPER ..............

  • Page 3: Introduction

    INTrOducTION Congratulations on purchasing the Skylink Wireless External Alarm SA-001 Series. The SA-001 Series provide you with a piercing siren and powerful features yet ease to use. You will find the installation to be simple and be able to get the unit up and running easily.
  • Page 4 Refer to the following table to setup the Wireless External Alarm to work with different Skylink’s Security System or Sensors. To select, you will see a jumper connector marked “J2” as shown below. Use a paper clip to remove the jumper connector and re-locate to the proper posts.

  • Page 5: Programming

    Plug in AC Insert the rechargeable battery pack Plug in AC adapter adapter to the black connector marked “NiMH” cAuTION: The adaptor as a disconnect devices: − the socket-outlet shall be installed near the equipment and shall be easily accessible. PrOgrAmmINg –...
  • Page 6 Learn/ Set 3B – Learn motion sensor to the Wireless External Alarm: - Press and hold the Learn button on the Wireless External Alarm for 2 seconds and then release. The Learn/Set LED will flash. - Activate the motion sensor by pressing the “Test/Set” button on the motion sensor.
  • Page 7 3C – Learn door/window sensor to the Wireless External Alarm: - Press and hold the Learn button on the Wireless External Alarm for 2 seconds and then release. The Learn/Set LED will flash. - Activate the Door/Window Sensor, by separating the magnets to send the signal. - You will hear 2 beeps and the LEDs will flash twice indicating the sensor is now programmed to the Wireless External Alarm.

  • Page 8: The Wireless External Alarm

    PrOgrAmmINg – ErAsE rEmOTE Or sENsOr Or cONTrOL PANEL FrOm ThE WIrELEss ExTErNAL ALArm To erase unwanted remote(s) or sensor(s) or control panel(s) from the Wireless External Alarm will erase all learned devices from the Wireless External Alarm. - Press and hold the Learn/Set button on the Wireless External Alarm for 8 seconds.

  • Page 9: Arming Sequence

    PrOgrAmmINg – ArmINg sEquENcE The Wireless External Alarm can be programmed to react 2 arming sequences when it receives the signal from the sensor. In order to arm the Wireless External Alarm, the remote (optional) must be programmed to the Wireless External Alarm. You may arm the Wireless External Alarm in 2 different sequences: AWAY PANIC...
  • Page 10 - You will hear 1 beep and the LEDs will flash once indicating the Wireless External Alarm is being counted to Away mode. - After 30 seconds, you will hear 2 beeps and the LEDs will flash twice indicating the Wireless External Alarm in Away mode. 6C –...

  • Page 11: Operating The Skylink Security Control Panel

    OPErATINg ThE skyLINk sEcurITy cONTrOL PANEL The Wireless External Alarm is designed to work with the Skylink security control panel such as AM-001, ML-001 and SC-001. Put the control panel that you plan to program into programming mode. Refer to the User’s Instructions of that control panel.

  • Page 12: Connect The Wireless External Alarm With Your Existing Alarm System

    Learn/ Set cONNEcT ThE WIrELEss ExTErNAL ALArm WITh yOur ExIsTINg ALArm sysTEm You may connect your existing alarm system with the Wireless External Alarm so that the Wireless External Alarm will be triggered by your alarm system. There are 2 ways you can connect your Wireless External Alarm with your existing alarm system.

  • Page 13: Alert Notification Jumper

    A LErT NOTIFIcATION JumPEr You can enable or disable the Alert Notification. When it is set to enable, the Wireless External Alarm will beep when arm or disarm or during the entry/exit countdown period. When it is set to disable, the Wireless External Alarm will not beep when arm or disarm or during the entry/exit countdown period.

  • Page 14: Battery

    (i.e. checking or cleaning the unit) sOLAr POWEr INsTALLATION (ONLy APPLIcABLE TO sA-001s) The External Wireless Alarm SA-001S is equipped with a solar panel, this solar pan- el is installed on top of the cover to charge rechargeable batteries during the day.

  • Page 15: Maintenance

    mAINTENANcE Your Wireless External Alarm requires few simple maintenance to ensure its con- tinued reliability and operation. - The solar panel on the top housing should be cleaned using the soft and damp cloth. This will ensure the solar panel receives all the available light. - Test the Wireless External Alarm periodically to ensure the unit is working.

  • Page 16: Trouble Shooting

    TrOuBLE shOOTINg Questions Solutions Why the Wireless External You must program the sensors or remote Alarm does not respond to the to the Wireless External Alarm before they sensors or remote? can work together. Why I can’t arm my system? Make sure none of the sensors are trig- gered.

  • Page 17: Fcc

    This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. WArNINg: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the...

  • Page 18: Warranty

    Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux ap- pareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : (1) l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement.

  • Page 19: Customer Service

    - find out the up-to-date specifications - know more about features and applications - download documents, i.e. user’s instructions - order Skylink products or if you have difficulty getting the products to work, please: 1. visit our FAQ section at www.skylinkhome.com, or 2.
  • Page 20 DEC,2012 101Y035...
