Troy Built Models Do-335 Instruction Manual
  1. Manuals
  2. Brands
  3. Troy Built Models Manuals
  4. Toy
  5. Do-335
  6. Instruction manual

Troy Built Models Do-335 Instruction Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Enlarged version
Do-335
Specification:
Length:
2140mm(84.3＂)
Wing span:
2121mm(83.5＂)
Wing area:
76.1sq.dm(8.2sq.ft)
Wing loading: 144.5g/sq.dm(47.4oz/sq.ft)
Flying weight: 11kg(24.2lbs)
Radio:
6ch & 11servos（including 4 medium-size servos）
Or 6ch & 13servos(When assemble two engines)
Engine:
50cc gasoline (Factory's recommendation)
Or one 1.20(frant) & one ．91(rear)

SAFETY PRECAUTIONS

INSTRUCTION MANUAL

This R/C airplane is not a toy!
(The people under 18 years old is forbidden from flying this model)
First-time builders should seek advice from people having building
experience.If misused or abused,it can cause serious bodily injury
and damage to property.
Fly only in open areas and preferably at a dedicated R/C flying site.
We suggest having a qualified instructor carefully inspect your
airplane before its first flight.Please carefully read and follow all
instructions included with this airplane,your radio control system
and any other components purchased separately.
