Hawker Typhoon
Specification:
Length
:1493 mm(60.9")
Wing Span
:1860 mm(73.2")
Wing Area
:55.3 sq. dm
5.95 sq. ft
Wing Loading :117.5 g/sq. dm
38.5 oz/sq. ft
Flying Weight :6.5 kg(14.3 lbs)
Radio
:6ch&8 servos
Engine
:108 2-cycle
120 4-cycle

SAFETY PRECAUTIONS

INSTRUCTION MANUAL

This R/C airplane is not a toy!
(The people under 18 years old is forbidden from flying this model)
First-time builders should seek advice from people having building
experience.If misused or abused,it can cause serious bodily injury
and damage to property.
Fly only in open areas and preferably at a dedicated R/C flying site.
We suggest having a qualified instructor carefully inspect your
airplane before its first flight.Please carefully read and follow all
instructions included with this airplane,your radio control system
and any other components purchased separately.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Hawker Typhoon and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Troy Built Models Hawker Typhoon

Summary of Contents for Troy Built Models Hawker Typhoon

  • Page 1: Instruction Manual

    Hawker Typhoon Specification: Length :1493 mm(60.9") Wing Span :1860 mm(73.2") Wing Area :55.3 sq. dm 5.95 sq. ft Wing Loading :117.5 g/sq. dm 38.5 oz/sq. ft Flying Weight :6.5 kg(14.3 lbs) INSTRUCTION MANUAL Radio :6ch&8 servos Engine :108 2-cycle 120 4-cycle...
  • Page 2 (with 9 servos), 6 channel radio for aiplane is highly recommended for this model. : 4-cycle .120 " 4.5 in Spinner Apply epoxy glue. Pre-cover the covering with clean cloth! Warning Start at low setting. Increase the setting if Remove the covering with proper necessary.If it is too high,you may damage pressure to cut through only the covering itself.Otherwise, the film.
  • Page 3 Assemble the aileron to main wing with instant type CA Accessory list for the coming installation steps. glue. Be careful to ensure the moving parts of the hinges Two wheel retract system are able to move freely. Clevis Retainer Rod (2x300mm) Make sure to assemble retracts as instructed below.
  • Page 4 Epoxy the landing gear to the main wing steadily. Adjustment. Secure the servo.Install the nylon control horn and Epoxy the main wing together. connect the linkage. A = A" TP Screw (2.3x12mm) A" 1.5mm Rod (2x300mm) Side View AILERON 20mm 20mm FLAP Screw (2x10mm)

  • Page 5: Assemble The Canopy

    Leave some space with width of 1mm between Epoxy the coolant radiator in the cowling steadily. Assemble the canopy. Install the servo as the illustration below. trailing edge and flap. TP Screw (2.3x8mm) Trailing Ply (15x15x3mm) edge Cowling Flap 1.5mm Epoxy plies inside the fuselage under the cowing and Make sure they are in the right position while...
  • Page 6 Be care to notice the distance between the wheel and Cut off the surplus PVC part carefully along the shaded Cut off the surplus parts carefully along the shaded line. Assembly of the main wings. fuselage. line Drill 6.2mm holes at the place of main wing.
  • Page 7 The sketch map when the tail landing gear be installed Drill two holes to the appropriate in the middle wing and Accessory list for the coming installation steps. Assemble the retract to the fuselage. mount the dowels in them . Retainer TP Screw(3x20mm) 70 mm...

  • Page 8: Pin Hinge(24X24Mm)

    Epoxy the fibreglass tubes to appropriate position as Epoxy the belly pant to appropiate position in the main below and leave some space with width of 1mm between Install the servo of switch in the fuselage. Install the servo of elevator. wing.

  • Page 9: Install The Rudder Servo

    Keep some space about 1mm width between the Mount the rudder servo to appropriate position in the The sketh map of the steel wires in the fuselage. Install the switch and the throttle servo fuselage. elevator and horizontal tail edge. Set screw (3x4mm) Tailing edge...
  • Page 10 Drill holes to appropriate position in the stabilizer and Drill four holes at the diameters as shown for engiine The sketch map when the engine install completion. Accessory list for the coming installation steps. mount. epoxy it to the fuselage as below. Washer(3x15mm) Clevis Lock Nut (3mm )
