Hawker hurricane MK.IIa
Specification:
Length
:1600 mm(63")
Wing Span
:2080 mm(82")
Wing Area
:60.2 sq. dm
6.69 sq. ft
Wing Loading :112.9 g/sq. dm
35.9 oz/sq. ft
Flying Weight :6.8kg(15 lbs)
Radio
:6ch&8 servos
Engine
:180
SAFETY PRECAUTIONS
INSTRUCTION MANUAL
This R/C airplane is not a toy!
(The people under 18 years old is forbidden from flying this model)
First-time builders should seek advice from people having building
experience.If misused or abused,it can cause serious bodily injury
and damage to property.
Fly only in open areas and preferably at a dedicated R/C flying site.
We suggest having a qualified instructor carefully inspect your
airplane before its first flight.Please carefully read and follow all
instructions included with this airplane,your radio control system
and any other components purchased separately.
Advertisement
Table of Contents
Related Manuals for Troy Built Models Hawker hurricane MK.IIa
Summary of Contents for Troy Built Models Hawker hurricane MK.IIa
-
Page 1: Instruction Manual
Hawker hurricane MK.IIa Specification: Length :1600 mm(63") Wing Span :2080 mm(82") Wing Area :60.2 sq. dm 6.69 sq. ft Wing Loading :112.9 g/sq. dm 35.9 oz/sq. ft Flying Weight :6.8kg(15 lbs) INSTRUCTION MANUAL Radio :6ch&8 servos Engine :180 This R/C airplane is not a toy! - Page 2 6 channel radio for aiplane is highly recommended for this model. :180 Optional parts: rubber wheel with metal hub, oleo struts and retracts system. 3.7 in Spinner 17″X6...
- Page 3 Assemble the aileron to main wing with instant type CA glue. Be careful Accessory list for the coming installation steps. to ensure the moving parts of the hinges are able to move freely. Two wheel retract system Clevis Retainer Make sure to assemble retracts as instructed below. Rod (2x300mm) TP Screw (2.3x12mm) Screw (3x35mm)
-
Page 4: Side View
The centre of the Gravity. The position of the control horn in the aileron. Install the servo as the illustration below Adjustment. Side View RUDDER 40mm 40mm 132mm 120mm Top view Secure the servo.Install the nylon control horn The front view and side view when the model install completion. Secure the servo with servo tray. - Page 5 Assemble the receiver and the battery to appropriate According to the rib template drill holes to the Epoxy the landing gear to the wing steadily. Connect the flap by a bended metal wire. in the fuselage. relevant position in the mid wing. Metal wire (1.8x220mm) 170º...
- Page 6 Epoxy plies inside the fuselage under the cowing and Install the servo. Epoxy the flaps to the wings as illustration. Accessory list for the coming installation steps. mount the cowing with TP screw as illustration. Nut (4mm) TP Screw (2.3x8mm) Washer(2x5mm) Screw (2x10mm) Wheel (100mm)
- Page 7 Cut off the surplus shaded portion carefully Cut away the shaded portion for assembling Assemble the tail wheel to the tail landing gear. The sketch maps when the retract up and down. of the items below. the gear house. centre wing side wing C"...
- Page 8 The sketch map of the linkage for the rudder Drill holes to appropriate position in the front of mid Epxoy the rudder to the fuselage steadily. Assembly of the stabilizer. and the tail wheel. wing and epoxy wood dowel in them. Make sure to glue securely.
- Page 9 The sketch map when assemble the tail landing Keep some space about 1mm width between Drill holes to appropriate position in the stabilizer and Drill a small hole to appropriate possition in the elevator and tailing edge. gear to the wheel steeling mount. fuselage for installing the plastical tube.
- Page 10 Drill 4 holes and set blind nut in appropriate position Engine installation finished sketch map. Accessory list for the coming installation steps. Install the servo. in the firewall before install the engine. Set screw (3x4mm) Clevis Blind Nut (4mm) Washer(3x15mm) Screw (4x35mm) Lock Nut (3mm ) Screw (4x25mm)
