Fw-190 D9(50cc)
Specification:
Length:
2100mm(82.5＂)
Wing span:
2093mm(82.5＂)
Wing area:
77.79sq.dm(8.42sq.ft)
Wing loading: 122g/sq.dm(40oz/sq.ft)
Flying weight: 9.5kg(20.9 bs)
Radio:
6ch & 8servos
Engine:
50cc gasoline engine
SAFETY PRECAUTIONS
INSTRUCTION MANUAL
This R/C airplane is not a toy!
(The people under 18 years old is forbidden from flying this model)
First-time builders should seek advice from people having building
experience.If misused or abused,it can cause serious bodily injury
and damage to property.
Fly only in open areas and preferably at a dedicated R/C flying site.
We suggest having a qualified instructor carefully inspect your
airplane before its first flight.Please carefully read and follow all
instructions included with this airplane,your radio control system
and any other components purchased separately.

Advertisement

loading
Need help?

Need help?

Do you have a question about the Fw-190 D9 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Troy Built Models Fw-190 D9

Summary of Contents for Troy Built Models Fw-190 D9

  • Page 1 Fw-190 D9(50cc) Specification: Length: 2100mm(82.5＂) Wing span: 2093mm(82.5＂) Wing area: 77.79sq.dm(8.42sq.ft) Wing loading: 122g/sq.dm(40oz/sq.ft) Flying weight: 9.5kg(20.9 bs) INSTRUCTION MANUAL Radio: 6ch & 8servos Engine: 50cc gasoline engine This R/C airplane is not a toy! (The people under 18 years old is forbidden from flying this model) First-time builders should seek advice from people having building experience.If misused or abused,it can cause serious bodily injury...
  • Page 2 Gasoline 6 channel radio for aiplane is highly recommended for this model. : 50cc gas engine Optional parts: rubber wheel with metal hub, oleo struts and retracts system. 4.8 in Spinner 22″X8-10 We strongly recommend you use the thread lock for all the screws when you build your model.
  • Page 3 Assemble the aileron to main wing with instant type CA glue. Be careful Accessory list for the coming installation steps. Two wheel retract system to ensure the moving parts of the hinges are able to move freely. Clevis Make sure to assemble retracts as instructed below. Clevis Collar (3mm) Rod (2.5x300mm)

  • Page 4: Side View

    Keep some space about 1mm width between Secure the servo.Install the nylon control horn Adjustment. The centre of the Gravity. trailing edge and flap. and connect the linkage. TP Screw (2.3x12mm) Trailing 1.5mm edge Side View Rod (2.5x300mm) AILERON 20mm Flap Nut (3mm ) Screw (3x10mm)

  • Page 5: Top View

    Trim the tail wheel cover and assemble it to The sketch map when assemble the tail landing Mount the gear door and the wheel to the retract. Install the nylon control horn and connect the linkage. fuselage with screw. gear to the wheel steeling mount. Tail wheel (45mm) TP Screw (2.3x8mm) Collar (3mm)
  • Page 6 Accessory list for the coming installation steps. According to the rib template drill holes to another Glue the exhaust to the fuselage as below. Epoxy the wheel wells to the wings. main wing. Wheel (115mm) Collar (6mm) Wooden Block(43x28x26mm) Landing gear(6mm) TP Screw (3x20mm ) Washer (3x6mm) Landing gear straps...
  • Page 7 According to the engine cut off the suplus part from the Cut away the surplus parts of canopy and PVC parts Drill holes in the wings and set the wood dowels Assemble the wings. former and glue it to the fuselage.as illustration.. carefully along the shade line.
  • Page 8 Drill holes to appropriate position in the stabilizer and Assemble the throttle servo in the fuselage. Install the servo of swith. Set the U-style wire through the enlarged hole as below. epoxy it to the fuselage as below. Steel wire (0.5x3000mm) U-style wire 150x25mm 1x20mm U-style wire 150x25mm...
  • Page 9 Drill four holes at the diameters as show Assemble the elevator sever to appropriate position Accessory list for the coming installation steps. Glue the elevator to the stabilizer by CA and epoxy. for engine mount. in the fuselage. Screw (5mm) (Not included) Washer(5mm) (Not included)
  • Page 10 Drill holes to appropriate position in the rudder and epoxy Drill a hole to the appropriate position through Assemble the tail wheel to the tail retract. Install the servo. the ping hinges in them the rudder as illustration. Bushing (4X4mm) Washer(2x5mm) Screw (2x10mm) Screw (3x50mm)
