TROY BUILT MODELS
105" Curtiss JN-4 Assembly Manual
For assistance call TBM at (941) 342-8685
This model is not a toy. Please use in a responsible and safe manner.

Features:

1) The wings come off the fuselage without disconnecting any flying wires. This makes for
easy set up at the field.
2) 35-50cc engine
3) 18 lbs ready to fly
4) Large tires for easy ground handling.
5) Uses analog servos
6) Flies very well, and landings are easy.

Parts Included with Kit:

1) Fuselage

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 105” Curtiss JN-4 and is the answer not in the manual?

Questions and answers

Related Manuals for Troy Built Models 105” Curtiss JN-4

Summary of Contents for Troy Built Models 105” Curtiss JN-4

  • Page 1 TROY BUILT MODELS 105” Curtiss JN-4 Assembly Manual For assistance call TBM at (941) 342-8685 This model is not a toy. Please use in a responsible and safe manner. Features: 1) The wings come off the fuselage without disconnecting any flying wires. This makes for easy set up at the field.
  • Page 2 2) Cowl 3) 2 Canopies...
  • Page 3 4) 3- piece wing for top and 2-piece wing for bottom. These will become a left and right wing section with the top and bottom wings remaining together for storage. 5) Rudder 6) Stabs 7) Landing Gear, tires, struts...
  • Page 4 8) Wing tip skids – these are CF rods 9) Tailwheel 10) Scale Engine...
  • Page 5 11) Fuel Tank 12) Hardware, control horns, flying wires, etc. 13) Struts Parts required to complete the kit: 1) 35-50cc engine 2) Muffler 3) Spinner not required. Full scale did not use a spinner. 4) Propeller 5) Pilot or 2 if desired 6) Hitec HS 645 servos for ailerons, elevators and rudder.
  • Page 6 15) Several servo plug clips which prevent plugs coming apart (TBM part# MPIclip or PPMJP) 16) Servo mounting screws 17) Engine mounting bolts, nuts and washers 18) We prefer two batteries about 2000 mah for the Rx with separate switches and regulators (if necessary) and one 1500 mah battery, switch and regulaor for the engine (if necessary).
