4 DIAGNOSTICS
The Interface Status fields are:
Field
DOCSIS Tuner & Xmitter
1394 I/O Device
USB I/O Device
Ethernet Device
Parallel Port
IR Xmit
Hard Drive Status
Smart Card
HDMI™ Port
EDID Data
Description
Indicates if enabled; indicates if active
Indicates if enabled; indicates if active
Indicates if enabled; indicates if active
Indicates if enabled; indicates if active
Indicates if enabled; indicates if active
Indicates if enabled; indicates if active
Indicates if enabled; indicates if active
Indicates if enabled; indicates if active
If a device is connected to the HDMI™ port only, the following
diagnostics display to help troubleshoot the HDMI™ interface.
They all display N/A if no device is connected to the HDMI™
port, or the value is invalid or cannot be retrieved.
•
Device Connected — Indicates whether a device is
connected to the HDMI™ port—Yes or No.
•
Repeater — Indicates whether the connected device is a
repeater — Yes or No.
•
Video Xmission (transmission) — Indicates whether the
DCX3200 is transmitting video over the HDMI™ port —
Not Active or Active.
•
HDCP Enabled — Indicates whether the DCX3200 is using
HDCP to encrypt video transmitted over the HDMI™ link
— Yes or No. If the Video Xmission status is Not Active,
the HDCP Enabled status is No.
•
Output Format — Indicates the timing format of the video
sent through HDMI:
•
1920 x 1080I — 1920 pixels wide by 1080 pixels high,
interlaced
•
1280 x 720P — 1280 pixels wide by 720 pixels high,
progressive
•
720 x 480P — 720 pixels wide by 480 pixels high,
progressive
•
720 x 480I — 720 pixels wide by 480 pixels high, interlaced
•
640 x 480P — 640 pixels wide by 480 pixels high,
progressive
•
Aspect Ratio — Indicates the aspect ratio of the video sent
through HDMI™ — 4:3 or 16:9
Indicates the video timing formats that were read from the
Extended Display Identification Data (EDID) register for the
connected device, in particular the detailed timing description
blocks. The list displays all of the formats that the DCX3200
could read, up to a maximum of 12 formats. If the DCX3200
cannot read any formats, EDID Data is blank. An asterisk (*)
after the aspect ratio means the DCX3200 supports the format.
If more than twelve video timing formats are discovered, the
supported formats only are listed first, followed by up to twelve
remaining formats.
