4 DIAGNOSTICS
The Code Modules fields are:
Field
Boot Code
Platform Built
Version
Processor
Analog
Secure
Processor
Downloadable
Object
Information
Table
Object
Ver
Status
Description
The boot code version in ASCII format.
The date platform software was built.
The firmware version and build date in ASCII format.
The digital secure processor version in ASCII format.
The analog secure processor version in ASCII format.
Lists all objects loaded, or being loaded, onto the DCX3400 in ASCII format.
The information displayed for each object depends on the running
environment. If a download is not in progress, the OSD displays the currently
running environment and version number.
The object name.
The object version.
The object status, updated on the OSD every 5 seconds while you display the
diagnostic:
OSD Status
MEM ALLOC Allocated
LOADING Loading
STARTING Enabling
ENABLED Enabled
ENA-NOT RUN Enabled_Not_ Runnable
STOPPING Disabling
DISABLED Disabled
Description
Memory for object is allocated
Object is being loaded
Object is being started (the
constructor is running)
Object is running
Object is enabled, but cannot
run
Object is being stopped (the
destructor is running)
Object has been disabled
47
