Motorola DCX3200 Installation Manual page 37

3 INSTALLATION
Setting
Audio Output
Return To Main
Page
Restore
Automatic
Settings
To configure the DCX3200 settings on the Additional Closed Caption Settings menu
screen:
1. Power off the DCX3200 and then immediately press the
control. This will display the main User Settings menu. Move the cursor next to the
"Closed Caption" option and adjust this setting to "Enabled. " The option to enter the
Additional Closed Caption Settings menu is now available.
Description
The Audio Output setting allows you to specify the digital audio format
delivered over the HDMI™ connection by the DCX3200. Options include
Auto, L-PCM, and Pass Through. By default, the Auto option is selected.
The options are used as follows:
•
Auto designates that the DCX3200 will provide the digital audio format
specified by the connected device (TV or home theater receiver) when
that device was first connected to the DCX3200.
•
L-PCM designates that the DCX3200 will provide all audio in the Linear
Pulse Code Modulation digital audio format. The L-PCM format is
widely supported by most HDMI™ televisions and home theater
receivers.
•
Pass Through designates that the DCX3200 will provide the same
digital audio format on the HDMI™ output as is provided with the
program being viewed at that time. For example, if the program has a
®
Dolby Digital soundtrack, the DCX3200 will pass the Dolby
audio to the HDMI™ output. This option is most useful when
connecting the DCX3200 to a home theater receiver that has HDMI™
switching capability.
Note 1: Adjusting these settings could result in a loss of audio. Only a
professional installer or someone with a good working knowledge of the
digital audio formats supported by the TV and/or home theater receiver
should change this setting
Selecting this option will return you to the main User Settings menu screen.
Selecting this option will restore all of the settings on this screen
(HDMI/DVI Mode, Color Space, and Audio Output) to their default value.
Use this option if audio and/or video have been lost after adjusting these
settings from their default values.
29
®
Digital
key on the remote
MENU
