Result Codes

When the modem receives an AT command from the terminal or PC, it
tries to execute the command, then sends a status message to the PC or
terminal which reports the "results" of the command (hence the name
"result codes"). The MultiModemZDX Command mode provides you with
several responses, or "Result Codes" , that provide visual responses
during Command mode operation. These Result Codes are displayed on
your PC's video monitor.
Terse Verbose
0 OK
1 CONNECT
2 RING
3 NO CARRIER
4 ERROR
5* CONNECT 1200
6 NO DIALTONE
7 BUSY
8 NO ANSWER
10* CONNECT 2400
11* CONNECT 4800
12* CONNECT 9600
13* CONNECT 14400
14* CONNECT 19200
24* CONNECT 7200
25* CONNECT 12000
26* CONNECT 16800
40* CONNECT 300
55* CONNECT 21600
56* CONNECT 24000
57* CONNECT 26400
58* CONNECT 28800
59* CONNECT 31200
60* CONNECT 33600
88 DELAYED
89 BLACKLISTED
90 BLACKLIST FULL
* EC is added to these Result Codes when the extended Result Codes configuration option is
enabled. EC is replaced by one of the following codes, depending on the type of error control
connection: V42bis (V.42 error control [LAP-M] and V.42bis data compression); V42 (V.42
error control [LAP-M] only); MNP5 (MNP 4 error control and MNP 5 data compression); MNP4
(MNP 4 error control only); NoEC (No error control protocol).
3 - AT Commands, S-Registers and Result Codes
Description
Command executed
Modem connected to line
Ring signal detected
Carrier signal lost or not detected
Invalid command
Connected at 1200 bps
No dial tone detected
Busy signal detected
No answer at remote end
Connected at 2400 bps
Connected at 4800 bps
Connected at 9600 bps
Connected at 14400 bps
Connected at 19200 bps
Connected at 7200 bps
Connected at 12000 bps
Connected at 16800 bps
Connected at 300 bps
Connected at 21600 bps
Connected at 24000 bps
Connected at 26400 bps
Connected at 28800 bps
Connected at 31200 bps
Connected at 33600 bps
Delay is in effect for the dialed number
Dialed number is blacklisted
Blacklist is full
