MT3334ZDX/V Owner's Manual
To install your MultiModemZDX:
1. Attach the MultiModemZDX to dial-up phone lines using the RJ11
telephone cord. This is accomplished by plugging one end of the
cable provided with the MultiModemZDX into the telephone jack in
your home or office; and plugging the other end into the LINE jack on
the MultiModemZDX.
The LINE jack is not interchangeable with the PHONE jack on the
MultiModemZDX. Do not plug the telephone into the LINE jack or the
line cable into the PHONE jack.
2. Attach your MultiModemZDX to your PC or terminal with an RS232
(or V.24) cable (see Figure 2-1). Be sure to tighten the mounting
screws on the DB connectors.
3. Connect your telephone set to phone jack via RJ11 cable.
4. Attach your MultiModemZDX to the AC Power transformer and
plugging the AC connector into a live AC outlet.
Turn on power by flipping the "ON/OFF" switch on the side of the
5.
MultiModemZDX to the "ON" position.
Note: Use only the power supply provided with the MultiModemZDX.
Use of any other power supply will void the warranty and could damage
the modem.
6. Make sure modem and computer/terminal serial port baud rates are
adjusted. (Note that several programs can check this for you. If you
have MS-DOS 5.0 or higher, a program called MSD.EXE [Microsoft
Diagnostics] is in your DOS directory. Typing MSD at the DOS
prompt brings up a screen that provides a variety of information about
your computer. Select COM ports and it lists information about your
com port, e.g., UART Type, Address, and IRQ, to name a few. Once
you know your serial port's UART type, you can set your
communications's software appropriately.)
7. Proceed to Chapter 3 of this manual, or to your data communications
software manual.
