USB
VDSL/ADSL
WAN2 (Giga)
GigaLAN (1-6)
PWR
ON/OFF
release the button. Then the router will restart with the factory
default configuration.
Connecter for a USB device (for 3G/4G USB Modem or printer).
Connecter for accessing the Internet.
Connecter for local network devices or modem for accessing
Internet.
Connecters for local network devices.
Connecter for a power adapter.
Power Switch.
7
Vigor2860 Series User's Guide
