D D e e t t a a i i l l s s P P a a g g e e f f o o r r P P
To choose PPPoE as the accessing protocol of the Internet, please select PPPoE from the
WAN>>Internet Access >>WAN1 page. The following web page will be shown.
Available settings are explained as follows:
Item
Enable/Disable
Modem Setting (for
ADSL only)
PPPoE Pass-through
overwritten.
DataType – Choose the type (ASCII or Hex or IP address)
for the data to be stored.
Data – Type the content of the data to be processed by the
function of DHCP option.
P P P P o o E E i i n n W W A A N N 1 1 ( ( P P
Description
Click Enable for activating this function. If you click
Disable, this function will be closed and all the settings that
you adjusted in this page will be invalid.
It is not necessary to configure settings in these fields for
modem settings are prepared for ADSL only.
The router offers PPPoE dial-up connection. Besides, you
also can establish the PPPoE connection directly from local
clients to your ISP via the Vigor router. When PPPoA
protocol is selected, the PPPoE package transmitted by PC
will be transformed into PPPoA package and sent to WAN
server. Thus, the PC can access Internet through such
direction.
87
h h y y s s i i c c a a l l M M o o d d e e : : V V D D S S L L 2 2 ) )
