CHAPTER 3
SETTING UP THE INTERACTIVE WHITEBOARD
To orient the interactive whiteboard
1. Press the Orientation button on the pen tray (see Power module buttons and indicators on
page 22).
The orientation screen appears.
2. Pick up a pen from the pen tray.
3. Beginning at the upper-left corner of the screen, touch the center of the target firmly with the
tip of the pen. When you remove the pen, the target moves to the next orientation point. Try
not to flick the pen when you lift it from the interactive surface, and make sure that you lift it
from the screen at a 90° angle.
NOTE
Although you can use your finger to orient your interactive whiteboard, a fine-point tool such
as a pen tray pen provides greater precision when touching the targets. The more precisely
you touch the targets, the more accurately your finger or pen tray pen appears on the
interactive screen.
Good orientation point
The pen touches the center of the target
4. Repeat step 3 until you complete the orientation process.
The orientation screen closes.
NOTE
You can re-orient a target by pressing the left arrow key on your keyboard, or the Keyboard
or Right-click buttons on the pen tray.
18 smarttech.com/kb/144817
Poor orientation point
