CHAPTER 2
INSTALLING AND SECURING THE SMART BOARD INTERACTIVE WHITEBOARD
Environmental
requirement
Dust
Conducted and
radiated emissions
Installing the SMART Board interactive
whiteboard
Follow the procedure outlined in the installation document included in the interactive whiteboard's
box to install the interactive whiteboard. If you purchased a floor stand, wall-mount or an interactive
whiteboard system that includes a projector or other components, refer to the installation
documents included with these components. The optimal mounting height is 77" (196 cm) from the
floor to the center of the installation brackets. However, consider the general height of your user
community when you choose a location for wall-mounting the interactive whiteboard. If you mount
the interactive whiteboard too low, it might force tall people to bend over uncomfortably. If it's too
high, other people might need to reach up too far. Also remember to leave enough room on either
side of the interactive whiteboard so that you can stand beside it.
WARNING
Safely mounting the interactive whiteboard requires two people. It is too heavy for one
l
person to safely maneuver. When you and your assistant lift the interactive whiteboard,
support its weight at the bottom, avoiding the corner cameras, and balance the top with
your other hands.
The weight of the interactive whiteboard is approximately 52 lb. (23.7 kg) for the 880 model
l
and 61 lb. (27.5 kg) for the 885 model. Check your local building codes to ensure that the
wall can support this weight, and use appropriate mounting hardware for the wall type.
CAUTION
If you need to lean the interactive whiteboard against a wall before you mount it, make sure
l
it remains in an upright position, resting on the pen tray brackets, which can sustain the
weight of the interactive whiteboard.
8 smarttech.com/kb/144817
Parameter
Moderate dust. Intended for use in office and classroom
l
environments. Not for industrial use where heavy dust and
pollutants can cause malfunctions or impaired operation.
Designed for pollution degree 1 (P1) as per EN61558-1, which is
l
defined as "No pollution or only dry non-conductive pollution."
EN55022/CISPR 22, Class A
