NetVanta 7000 Series Hardware Installation Guide
5.

UNIT INSTALLATION

The instructions and guidelines provided in this section cover hardware installation topics such as
mounting options, supplying power to the unit, and installing option cards. These instructions are
presented as follows:
• Mounting Options on page 44
• Supplying Power to the Unit on page 46
• Installing Dial Backup and Network Interface Modules on page 47
For information on configuring a specific application, refer to the quick configuration documents provided
on your ADTRAN OS System Documentation CD or the Command Line Reference Guide (also included on
your CD).
To prevent electrical shock, do not install equipment in a wet location or during a
lightning storm.
Electronic modules can be damaged by static electrical discharge. Before handling
modules, put on an antistatic discharge wrist strap to prevent damage to electrical
components. Place modules in antistatic packing material when transporting or storing.
When working on modules, always place them on an approved antistatic mat that is
electrically grounded.

Tools Required

The customer-provided tools required for the hardware installation of the NetVanta 7100 are:
• Ethernet cables
• Network cables (module dependent)
• DSX-1 cable (T1/FT1 + DSX-1 module only)
• DBU cable (dial backup functions require an optional DIM)
• Phillips-head screwdriver
To access the command line interface (CLI) of the NetVanta 7100, you will also need a
VT100 terminal or PC with terminal emulation software and a console port cable.
Instructions on how to access the CLI are given in the Command Reference Guide
(provided on the ADTRAN OS System Documentation CD).
61200796L1-34D Copyright © 2006 ADTRAN, Inc.
Unit Installation
43
