Total Access 900e Series Hardware Installation Guide
4.

UNIT INSTALLATION

The instructions and guidelines provided in this section cover hardware installation topics such as wall
mounting, rack mounting, and installing the unit. Refer to
started. The instructions are presented as follows:
• Tools Required on page 21
• Mounting Options on page 22
• Grounding Instructions on page 24
• Supplying Power to the Unit on page 25
For information on Total Access 900e Series configuration for a specific application, refer to the configuration
guides provided on the ADTRAN Support
the AOS Command Reference
http://supportforums.adtran.com.
To prevent electrical shock, do not install equipment in a wet location or during an
electrical storm.
• The Total Access 900e Series is intended to be installed, maintained, and serviced by
qualified service personnel only.
• Ethernet cables are intended for intrabuilding use only. Connecting an ADTRAN unit
directly to Ethernet cables that run outside the building in which the unit is housed will
void the user's warranty and could create a fire or shock hazard. To connect an
ADTRAN unit to Ethernet cables that run outside the building, ADTRAN's Ethernet
Port Protection Device (EPPD) (P/N 1700502G1) must be connected between the unit
and the outside plant cable. Use of any Ethernet protector other than ADTRAN's for
this purpose will void the user's warranty.

Tools Required

The following customer-provided tools are required for installation of the Total Access 900e Series
hardware:
• Two wood screws, 3/32-inch to 1/8-inch (1-inch or greater length)
• Drill and drill bit set
• Screwdriver (medium)
• 25-pair male amphenol cable (customer connection)
• Selected punch-down block and tool
• To access the CLI of the Total Access 900e, you will also need a PC with terminal
emulation software and a console port cable. Instructions on how to access the CLI are
available in the quick start guide shipped with your unit or online at
Support
• Refer to your Total Access 900e Series quick start guide shipped with your unit or
available online at
GUI and the CLI.
64243916F1-34A
Community. For details on the command line interface (CLI), refer to
Guide. All other related documents are also available online at
Forum.
ADTRAN's Support Forum
Copyright © 2010 ADTRAN, Inc.
Shipping Contents on page 14
for instructions on how to access the
Unit Installation
before getting
ADTRAN's
21
