Appendix A. Connector Pin Definitions

Table A-3. 1000BaseT Gigabit-Ethernet Port Pinouts

Pin Name
1 TRD0+
2 TRD0-
3 TRD1+
4 TRD2+
5 TRD2-
6 TRD1-
7 TRD3+
8 TRD3-

Table A-4. Analog - Onboard FXS and FXO Port Pinouts

Pin Name
1,2 —
3 Ring
4 Tip
5,6 —

Table A-5. Alarm Contacts

Pin Name Description
NO
NC
COM
50
Transmit/Receive Positive
Transmit/Receive Negative
Transmit/Receive Positive
Transmit/Receive Positive
Transmit/Receive Negative
Transmit/Receive Negative
Transmit/Receive Positive
Transmit/Receive Negative
Description
Unused
Ring lead of the 2-wire interface
Tip lead of the 2-wire interface
Unused
Normally Open
Normally Closed
Common
Copyright © 2006 ADTRAN, Inc.
NetVanta 7000 Series Hardware Installation Guide
Description
61200796L1-34D
