NetVanta 7000 Series Hardware Installation Guide
Network Interface Module Pinouts

Table A-6. WAN-DDS Connector Pinouts

Pin Name
1 R1
2 T1
3-6 —
7 T
8 R

Table A-7. WAN-T1 Connector Pinouts

Pin Name
1 R1
2 T1
3 —
4 R
5 T
6-8 —

Table A-8. WAN-E1 Connector Pinouts

Pin Name
1 R1
2 T1
3 —
4 R
5 T
6-8 —
61200796L1-34D
Description
Transmit data to the network–Ring 1
Transmit data to the network–Tip 1
Unused
Receive data from the network–Tip
Receive data from the network–Ring
Description
Receive data from the network–Ring 1
Receive data from the network–Tip 1
Unused
Transmit data toward the network–Ring
Transmit data toward the network–Tip
Unused
Description
Receive data from the network–Ring 1
Receive data from the network–Tip 1
Unused
Transmit data toward the network–Ring
Transmit data toward the network–Tip
Unused
Copyright © 2006 ADTRAN, Inc.
Appendix A. Connector Pin Definitions
