BILL OF MATERIALS

1.8 V OUTPUT, 300 kHz, 14 A APPLICATION CIRCUIT

Table 2.
Reference
Name Designator
C C1
VDD
C C2
VDD
C C3
IN
C C4
IN
C C5
IN
C C6
IN
C C7
IN
C C8
IN
C C10
PAR
C C11
C
C C12
BST
C C13
SNUBBER
C C14
OUT
C C15
OUT
C C16
OUT
C C17
OUT
C C18
OUT
C C19
OUT
C C20
OUT
C C21
OUT
C C22
OUT
C C23
OUT
C C24
OUT
R R1
TOP
R R2
BOT
R R3
C
R R4
GATE
R R5
RES
R R6
SNUBBER
Top MOSFET Q1
Top MOSFET Q2
Bottom MOSFET Q3
Bottom MOSFET Q4
Inductor L1
Header J1
Header JP2
Header JP3
Banana Plugs TP_VIN1
Banana Plugs TP_PGND
Banana Plugs TP_VOUT1
Controller/Driver U1
Diode D3
1 Components from other manufacturers can also be used, as long as the characteristics listed in the corresponding description are met.
2 Z = RoHS Compliant Part.
Value Unit Manufacturer
1.0 µF Taiyo Yuden
0.1 µF TDK
22 µF Murata
22 µF Murata
22 µF Murata
22 µF Murata
22 µF Murata
N/A N/A
57 pF Taiyo Yuden
571 pF Taiyo Yuden
100 nF Taiyo Yuden
1.5 nF Taiyo Yuden
N/A N/A
N/A N/A
N/A N/A
N/A N/A
N/A N/A
N/A N/A
270 µF Panasonic
270 µF Panasonic
270 µF Panasonic
270 µF Panasonic
N/A N/A
30 kΩ Vishay 1
15 kΩ Vishay 1
47 kΩ Vishay 1
0 kΩ Vishay 1
100 kΩ Vishay 1
2 Ω Vishay
1
N/A N/A Infineon
N/A N/A Infineon
N/A N/A Infineon
N/A N/A Infineon
1.0 µH Würth Elek
N/A N/A
N/A N/A
N/A N/A
N/A N/A
N/A N/A
N/A N/A
N/A N/A Analog Devices
N/A N/A
Rev. A | Page 16 of 20
ADP1872-EVALZ/ADP1873-EVALZ User Guide
Description/Model
1.0 µF, 6.3 V, X5R ceramic capacitor (0402), JMK105BJ105KV-F
0.1 µF, 25 V, X5R ceramic capacitor (0402), C1005X5R1E104K
25 V, X7R, 1210 (3.2 mm × 2.5 mm × 2.5 mm) GRM32ER71E226KE15L
25 V, X7R, 1210 (3.2 mm × 2.5 mm × 2.5 mm) GRM32ER71E226KE15L
25 V, X7R, 1210 (3.2 mm × 2.5 mm × 2.5 mm) GRM32ER71E226KE15L
25 V, X7R, 1210 (3.2 mm × 2.5 mm × 2.5 mm) GRM32ER71E226KE15L
25 V, X7R, 1210 (3.2 mm × 2.5 mm × 2.5 mm) GRM32ER71E226KE15L
1 ±10%, 50 V, X7R ceramic capacitor (0402)
1 ±5%, 50 V, C0H ceramic capacitor (0402)
±10%, 50 V, X7R ceramic capacitors (0603)
1
1 ±10%, 50 V, X7R ceramic capacitors (0603)
SP-series, 4 V, 7 mΩ, 3.7 A EEFUE0G271LR (4.3 mm × 7.3 mm × 4.2 mm)
SP-series, 4 V, 7 mΩ, 3.7 A EEFUE0G271LR (4.3 mm × 7.3 mm × 4.2 mm)
SP-series, 4 V, 7 mΩ, 3.7 A EEFUE0G271LR (4.3 mm × 7.3 mm × 4.2 mm)
SP-series, 4 V, 7 mΩ, 3.7 A EEFUE0G271LR (4.3 mm × 7.3 mm × 4.2 mm)
±1% resistors (0603)
±1% resistors (0603)
±1% resistors (0603)
±1% resistors (0603)
±1% resistors (0603)
±1% resistors (0603)
BSC080N03MS G
BSC080N03MS G
BSC080N03MS G
BSC080N03MS G
7443251200
ADP1872ARMZ-0.3-R7 2 (LDT) or ADP1873ARMZ-0.3-R7 2 (LDF)
