Sc846 Chassis Manual
3-2
Control Panel Buttons
The chassis includes two push-buttons that control power to the system.
Power
The main power switch applies or removes primary power from the power supply
to the server but maintains standby power. To perform most maintenance tasks,
unplug the system to remove all power..
Reset
The reset button is used to reboot the system.
3-3
Control Panel LEDs
There are six LEDs that provide status information about the system.
Power
Indicates power is being supplied to the system power supply units. This LED is
illuminated when the system is operating normally.
HDD
Indicates activity on the hard disk drive when flashing.
3-2
